Low Peak Fuse, Class CC, 0.60A, 1.5 Inch Height, 200 kAIC Interrupt Rating

Low Peak Fuse, Class CC, 0.60A, 1.5 Inch Height, 200 kAIC Interrupt Rating - https://images.province-electric.com/BUS-LP-CC-6-slash-10/low-peak-fuse-bussmann-medium-alt-govt.webp

Documentation & Downloads

Bussmann LP-CC-6/10 Low Peak Fuse, Class CC, 0.60A, 1.5 Inch Height, 200 kAIC Interrupt Rating

MPN: LP-CC-6/10
UPC: 051712180412
PPN: BUS-LP-CC-6/10

CAD

$17.92

/ EA

Available to Order

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Company Stock:

Qty:

Loading add to cart quantity...

Looking to buy a large quantity?

To view product inventory

Spec sheet

Compare

Description

Low Peak Fuse, Class CC, 0.60A, 1.5 Inch Height, 200 kAIC Interrupt Rating

Features

Featuring a time-delay, dual-element design, this $0.6\text{-Amp}$ fuse delivers time-delay performance for harmless transient surges while providing fast-acting protection against catastrophic short circuits. It effectively eliminates premature "nuisance blows" during demanding inductive motor start-ups or transformer energization cycles, keeping your automation lines running without sacrificing system safety.
Boasting a massive 200kA interrupting rating at 600VAC, this compact Midget-sized fuse is engineered to isolate extreme short-circuit currents safely. It provides robust protection for sensitive branch circuits and complies fully with NEC® Section 110.9 for high available fault current environments, preventing catastrophic arc-flash damage and equipment destruction.
Outfitted with a physical Class CC rejection tip, this fuse is specifically keyed to fit only into specialized rejection-style fuse holders and blocks. This critical safety architecture prevents field technicians from accidentally substituting standard, lower-rated 10 times 38mm supplemental fuses, maintaining your system's UL/CSA branch circuit rating and ensuring ongoing code compliance.
Classified as a highly current-limiting device, the LP-CC-6/10 rapidly opens and clears a severe fault within milliseconds—long before the peak destructive current can form. This rapid clearing action minimizes total thermal energy (I^2t) and mechanical stress, safeguarding vulnerable downstream components like PLCs, relays, and variable frequency drives (VFDs) from terminal burnout.

Documentation & Downloads

Specifications

Additional

Fuse Class: Class CC

Voltage Rating: 600 Vac, 300 Vdc

Response Time: 12 s at 200% rated current

Height: 1.5 in

Width: 0.41 in

Connection: Ferrule end x ferrule end

Fuse Type: Current-limiting, Time-delay

Weight: 0.15 lb

Amperage Rating0.60 A

Interrupt Rating200 kAIC at 600 Vac, 20 kAIC at 150 Vdc

Diameter0.41 in

Length0.41 in

Number Of ElementsDual

MaterialMelamine tube

Fuse IndicatorNon Indicating

Special FeaturesRejection Style
