Rejection Style Fuse, 3A, 600 Vac, 150 Vdc, Class CC, Melamine Tube

Rejection Style Fuse, 3A, 600 Vac, 150 Vdc, Class CC, Melamine Tube - https://images.province-electric.com/BUS-LP-CC-3/eaton-bussmann-series-lp-cc-medium-alt-aedb.webp

Documentation & Downloads

Bussmann LP-CC-3 Rejection Style Fuse, 3A, 600 Vac, 150 Vdc, Class CC, Melamine Tube

MPN: LP-CC-3
UPC: 051712180290
PPN: BUS-LP-CC-3

CAD

$17.20

/ EA

Available to Order

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Company Stock:

Qty:

Loading add to cart quantity...

Looking to buy a large quantity?

To view product inventory

Spec sheet

Compare

Description

Rejection Style Fuse, 3A, 600 Vac, 150 Vdc, Class CC, Melamine Tube

Features

The Bussmann LP-CC-3 is a Class CC Low-Peak™ fuse, engineered to provide the highest level of protection in a compact size. As a "Current-Limiting" fuse, it reacts in less than half a cycle (0.008 seconds) to "clamp" short-circuit energy before it reaches its destructive peak. This is essential for protecting sensitive contactors, solid-state relays, and PLCs in Canadian industrial control panels from catastrophic failure.
Despite its small size, this 3-Amp fuse features dual-element, time-delay characteristics. It is specifically designed to withstand the heavy momentary surges of small motor starts and control transformer inrush. It provides a minimum 12-second delay at 200% of its rated current, preventing "nuisance blowing" during startup while still offering high-speed protection against dangerous faults.
As a Class CC fuse, the LP-CC-3 features a unique physical rejection tip. This ensures it can only be installed in a dedicated Class CC fuse holder (like the Bussmann CHCC series), preventing the accidental installation of standard "midget" fuses that lack the high interrupting rating and branch-circuit certification required by code.
The LP-CC-3 is fully rated for 600V AC and boasts a massive 200,000 Amp Interrupting Rating (AIR). This allows it to be used safely in almost any Canadian industrial or commercial power system, regardless of the available fault current at the service entrance, ensuring your installation remains safe and fully compliant with the Canadian Electrical Code (CEC).

Documentation & Downloads

Specifications

Additional

Amperage Rating: 3A

Interrupting Rating: 200 kA at 600 Vac, 20 kA at 150 Vdc

Fuse Type: Current-limiting, Time-delay

Length: 1.5 in

Material: Melamine tube

Number of Elements: Dual

Fuse Indicator: Non Indicating

Special Features: Rejection Style

Voltage Rating600 Vac, 150 Vdc

ClassClass CC

Response Time12 seconds at 200% rated current

Diameter0.41 in

ComplianceUL Listed, CSA Certified, CE Marked, RoHS compliant

Connection TypeFerrule end X ferrule end

Product Weight0.15 lb
