Bussmann LP-CC-2 Current-limiting Fuse, 2A, 600 Vac, 300 Vdc, Ferrule End, Time-delay
Bussmann LP-CC-2 Current-limiting Fuse, 2A, 600 Vac, 300 Vdc, Ferrule End, Time-delay
- MPN: LP-CC-2
- UPC: 051712180269
- PPN: BUS-LP-CC-2
In Stock
Company Stock:
00
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To view product inventory
CAD$17.20/ EA
Description
Current-limiting Fuse, 2A, 600 Vac, 300 Vdc, Ferrule End, Time-delay
Features
- Measuring a compact 13/32" x 1-1/2", this current-limiting fuse features a specialized rejection tip designed specifically for matching Class CC fuse blocks. This mechanical fail-safe physically prevents the dangerous accidental installation of lower-rated supplemental fuses, ensuring your commercial branch circuits remain properly rated and fully compliant with NEC requirements.
- Engineered with a robust 12-second minimum time delay at 200% of its 2-amp rating, this Bussmann fuse safely absorbs temporary, harmless motor startup spikes and control power transformer surges. This essential characteristic eliminates the costly manufacturing downtime associated with frustrating nuisance blowing, while still delivering highly responsive, pinpoint protection against sustained destructive overloads.
- Built with a durable, arc-quenching melamine tube, this high-performance fuse safely interrupts massive fault currents up to 200,000 Amps RMS at 600V AC. By rapidly limiting peak let-through thermal and magnetic energy, it actively shields your valuable electrical infrastructure from catastrophic damage, minimizing arc flash hazards and ensuring strict workplace safety.
- This Low-Peak series component is specifically engineered to deliver premium IEC Type 2 "No Damage" protection for motor control circuits. In the event of a severe short circuit, your sensitive NEMA and IEC contactors and relays remain completely undamaged and operational, drastically reducing replacement hardware costs and allowing technicians to restart critical machinery by simply swapping the blown fuse.
Specifications
- Voltage
- 600 Vac, 300 Vdc
- Interrupting Rating
- 200 kA at 600 Vac, 20 kA at 300 Vdc
- Connection Type
- Ferrule end X ferrule end
- Length
- 1.5 in
- Product Weight
- 0.15 lb
- Material
- Melamine tube
- Compliance
- UL Listed Class CC, CSA Certified, CE Marked, RoHS Compliant
Amperage2A
Response TimeMinimum 12 seconds at 200% rated current
Diameter0.40625 in
Width0.41 in
Fuse TypeCurrent-limiting, Time-delay
ClassClass CC
