Bussmann

Bussmann LP-CC-4 Low Peak Current-Limiting Fuse, 4 A, 600 Vac, Class CC, Ferrule Connection

Low Peak Current-Limiting Fuse, 4 A, 600 Vac, Class CC, Ferrule Connection
Low Peak Current-Limiting Fuse, 4 A, 600 Vac, Class CC, Ferrule Connection
  • MPN: LP-CC-4
  • UPC: 051712180320
  • PPN: BUS-LP-CC-4

Spec sheet

In Stock

Company Stock:

00

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Looking to buy a large quantity?

To view product inventory

CAD$17.20/ EA

Description

Low Peak Current-Limiting Fuse, 4 A, 600 Vac, Class CC, Ferrule Connection

Features

  • As a specialized Low-Peak™ rejection-style fuse, this 4-amp component is designed to be significantly more current-limiting than standard fuses. It rapidly interrupts fault currents before they reach their peak, shielding sensitive branch circuit components, such as small motor controllers and solid-state relays, from the violent thermal and magnetic forces of a short circuit.
  • Built with a dual-element time-delay design, this fuse allows for a temporary 12-second surge at 200% of its rated current to accommodate the high inrush demands of control transformers and small motors. This advanced engineering eliminates "nuisance tripping," ensuring your industrial machinery stays operational during startup while providing 600V AC protection for sustained overloads.
  • With a massive 200,000 Amp interrupting rating at 600V, this fuse is capable of safely clearing catastrophic faults even in high-density electrical environments. Utilizing a high IR fuse ensures that your control panels meet the most stringent Short Circuit Current Rating (SCCR) requirements, protecting your facility and personnel from explosive arc-flash events.
  • The physical design features a unique rejection tip that prevents the installation of physically similar but lower-rated fuses (like Class M midget fuses) into the circuit. This "safety-first" mechanical design ensures that only a high-interrupting, current-limiting Class CC fuse can be used, maintaining the integrity of your UL 508A industrial control panel certification.
  • Measuring just 13/32" x 1-1/2", this compact fuse delivers heavy-duty protection without occupying the large footprint of Class R or Class J fuses. It is the ideal solution for modern, space-constrained enclosures where high-performance branch circuit protection is required for solenoid valves, contactors, and control power transformers.

Specifications

Amperage
4 A
Interrupt Rating
200 kA at 600 Vac, 20 kA at 150 Vdc
Class
Class CC
Connection
Ferrule end x ferrule end
Diameter
0.40625 in
Product Width
0.41 in
Product Weight
0.15 lb
Compliance
CE Marked, RoHS Compliant, UL Listed, CSA Certified
Voltage600 Vac, 150 Vdc
TypeCurrent-limiting, Time-delay
Number of ElementsDual
Response Time12 sec at 200%
Product Length/Depth1.5 in
Product Height0.41 in
MaterialMelamine tube
