Hubbell Wiring Device-Kellems HBL460MIF12W IEC Pin and Sleeve 60A Female Receptacle, 125/250V, Watertight

IEC Pin and Sleeve 60A Female Receptacle, 125/250V, Watertight - https://media.province-electric.com/325/synd_hubbell/medium/8e675d788ede22d05f47a5daf553cdc6597bf378-medium.png

IEC Pin and Sleeve 60A Female Receptacle, 125/250V, Watertight

MPN: HBL460MIF12W
UPC: 783585406008
PPN: HBL-HBL460MIF12W
UNSPSC: 39121406

Spec sheet

Compare

Loading compare button...

In Stock

Company Stock:

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$3760.08/ EA

Qty:

Loading add to cart quantity...

Description

Heavy Duty IEC Pin and Sleeve Industrial Grade Female Fused Mechanically Interlocked Receptacle, 60A 125/250V, 3-Pole 4-Wire Grounding, Terminal Screws

Features

Replaceable spring-loaded receptacle liftcover with gasket
Removable door for ease of wiring and installation
Plug-Check™ mechanism to detect the presence of plug
Watertight

Specifications

Country of Origin: PL

Width: 12.200 in

Industry Standard(s): CSA Certified;UL Listed for US and Canada

Amperage Rating: 60 A

Color: Orange

NEMA Rating: Non-NEMA

Number of Wires: 4-Wire

Special Features: Watertight

Type: Mechanical Interlock

Wattage: 15000

Voltage Rating Description: 120/240 VAC

Display Size: Standard Sized Product

Number Of Poles: 3-Pole

Style: Standard Service

Description - Invoice: PS, IEC, MECINT, 3P4W, 60A 125/250V,FUSE

Harmonization Code: 8537109170

MSDS Flag: No

Sub Class Code: A12A210

Current Rating: 60 A

Series: Fused

Carton - SCC-14 Next Lower Level Sub Pack: 00783585406008

Lowest Level UOM: Each

Current / Amperage Rating60 A

Each - Width12.200 in

PerformanceElectrical - Current Interrupting - Certified for current interrupting at full rated current and voltage;Electrical - Dielectric Voltage - Withstands 3,000V AC Min;Electrical - Max Working Voltage - 600V AC;Environmental - Flammability - UL94-5VA and V-0 Classification;Environmental - Ingress Protection - IP66 Suitability;Environmental - Operating Temperatures - Max. Continuous +75°C;Min. Continuous -40°C;Environmental - UV Resistance - All materials are UV stabilized;Mechanical - Impact Resistance - In accordance with UL 746C;Mechanical - Mounting - External adjustment feet;Mechanical - Terminal Identification - In accordance with UL, CSA and international conventions

ApplicationHigh Ampacity Connections

Environmental ConditionsWatertight

Number of Poles3-Pole

PhaseSingle Phase

StandardCSA Certified;UL Listed for US and Canada

Voltage Rating120/240 VAC

Wire Size#8 AWG to #2 AWG

ConnectivityPressure Terminal Screws

Nema RatingNon-NEMA

Number Of Wires4-Wire

Class CodeA12

Freight Class Code06168002

Image Actual Or RepresentativeA

Replaced Catalog Number460MIF12W

Material - Mounting HardwareScrew Mounting

MaterialThermoplastic

Base Unit of MeasureEA

Each - Pack DescriptionEach

Certifications

EU RoHS Indicator: No
