Littelfuse KSPUA8C KSPUA8C - KSPUA Counter Series
- MPN: KSPUA8C
- UPC: 079458995909
- PPN: LTF-KSPUA8C
CAD
$147.92
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
KSPUA8C - KSPUA Counter Series
Documentation & Downloads
Specifications
Key Specifications
- Input Voltage (V)
- 24 to 240VAC
- Input AC Line Frequency (Hz)
- 50/60Hz
- Output Load Rating (VA)
- 1A steady state 10A inrush for 16ms
- Time Delay Type
- Microcontroller circuitry
- Initiate Time (ms)
- ≤20ms
- Count Range
- 1 - 1 023
- Repeat Accuracy (%)
- ±0.1% or 20ms whichever is greater
- Setpoint vs Ambient Temperature and Operating Voltage (%)
- ≤ ±5%
- Insulation Resistance
- ≥100 MΩ
- Circuitry
- Encapsulated
- Termination Type
- 0.25 in. (6.35mm) male quick connect terminals
- Operating Temperature
- -40° to 60°C (-40°F to 140°F)
- Humidity
- 95% relative non-condensing
- Weight (lbs/g)
- ≅2.4oz (68g)
Input Tolerance (%)±15%
Output TypeSolid state
Output Voltage Drop (V)≅2.5V @ 1A
Reset Time (ms)≤150ms
Count Rate (per second)≤25 counts per second
Counter Function/OutputOutput pulse width: 300ms ±20%; Time Delay/Counts Variable
Setting Accuracy≤±2% or 20ms whichever is greater
Open State Leakage Current (A)≅5mA @ 240VAC
Dielectric Breakdown≥2000V RMS terminals to mounting surface
Power Consumption≤2VA
Mounting MethodSurface mount with one #10 (M5 x 0.8) screw
Storage Temperature (F/C)-40° to 85°C (-40°F to 185°F)
Dimensions2.00 x 2.00 x 1.21 in. (50.8 x 50.8 x 30.7mm)
Sample capableNo
