Line Choke 2 mH 18 A Single Phase 30 W
Schneider Electric

Schneider Electric VZ1L018UM20 Line Choke 2 mH 18 A Single Phase 30 W

  • MPN: VZ1L018UM20
  • PPN: SCH-VZ1L018UM20
  • If you can't find the product or are unsure which one you need, please use the Product Selector tool below

    • CAD

    $157.49

    / EA

    Available to Order

    Lead times may vary. For an accurate estimate please contact us.

    Company Stock:

    0

    Loading dialog...

    Looking to buy a large quantity?

    To view product inventory

    Spec sheet

    Description

    This line choke can be used to provide improved protection against overvoltages on the line supply. It can also be used to reduce harmonic distortion of the current produced by the drive. This product is compliant with IEC 61800-5-1 (VDE 0160 level 1 high-energy overvoltages on the line supply). Its rated current is equal to 18A and its value of inductance to 2mH. It is compatible with Altivar 31, Altivar 32, Altivar 312, Altivar machine ATV320, Lexium 05 and Lexium 32.

    Documentation & Downloads

    Specifications

    Key Specifications

    Country of Origin
    Brazil, France
    Depth105 mm

    Complementary Attributes

    Line Rated Current
    18 A
    Maximum Voltage Drop At Rated Load5 %

    Important Information Attributes

    Certificate Agency
    VDE 0160 level 1, IEC 60076 (with HD398), EN 50178
    Local Publishable Date
    2026-01-12
    Stocking Flag
    N
    Device Type
    Variable speed drive - VSD option & accessory
    Traceability
    No
    Weee Scope
    Out
    Scope Perimeter
    At least in Europe
    Reach Full Compliance Status Id
    NOT_CONTAINING_SVHC
    Rohs Eur In Scope
    No
    Rohs Eur Conformity Date
    2017
    China Rohs In Scope
    Yes
    With Recycled Cardboard
    No
    Product Contributes To Saved And Avoided Emissions
    No
    Persona Type Names
    End User
    Tier
    1
    Function Option
    Standard
    Market Segmentation
    Industrial
    Device Application
    reduction of current harmonics
    Product Availability
    Stock - Normally stocked in distribution facility
    Range Of Product
    Altivar
    Supply Frequency
    50...60 Hz
    Thermal Losses
    30 W
    Height Nominal
    120 mm
    Accessory / Separate Part Category
    protection accessories
    Package Weight(Lbs)
    1.928 kg
    Warranty (In Months)
    18
    Local Data StatusPublishable
    Return IndicatorY
    Stock Policy2
    ServiceabilityNo
    Weee ApplicabilityComponent
    Weee Exclusion RationaleComponent not in scope – non independent function
    Reach Full Compliance StatusFree of Substances of Very High Concern above the threshold
    Reach Compliance DirectiveFree of Substances of Very High Concern above the threshold
    Rohs Eur StatusCompliant
    Rohs Eur Full Compliance StatusCompliant
    China Rohs Label1
    Without Single Use PlasticNo
    Persona Type IdsEU
    Tier Id1
    Function Option IdSTANDARD
    Market Segmentation IdINDUSTRIAL
    Product Kit IdentifierN
    Phasesingle phase
    Product Or Component Typeline choke
    ReturnabilityYes
    Sustainable PackagingNo
    Value Of Inductance2 mH
    Width Nominal85 mm
    Nbr. Of Units In Pkg.1
    Take-backNo

    Environment Attributes Main

    Ip Degree Of Protection
    choke IP00, terminals IP20
    Take Back
    No
    Recycled Metal Content At Cr Level
    0 %
    Toxic Heavy Metal Free
    Yes
    Eu Rohs Directive
    Compliant
    Packaging Without Single Use Plastic
    No
    Reach Regulation
    Free of Substances of Very High Concern above the threshold
    Product CompatibilityATV312HU11M2 - line choke - 1 per drive, ATV312HU15M2 - line choke - 1 per drive, ATV312HU22M2 - line choke - 1 per drive, ATV31CU11M2 - line choke - 1 per drive, ATV31CU15M2 - line choke - 1 per drive, ATV31CU22M2 - line choke - 1 per drive, ATV32HU11M2 - line choke - 1 per drive, ATV32HU15M2 - line choke - 1 per drive, ATV32HU22M2 - line choke - 1 per drive, LXM05D17F1 - line choke - 1 per drive, LXM05D17M2 - line choke - 1 per drive, LXM05D28F1 - line choke - 1 per drive, LXM05D28M2 - line choke - 1 per drive, LXM32.D18M2 - line choke - 1 per drive, LXM32.D30M2 - line choke - 1 per drive, LXM32.U90M2 - line choke - 1 per drive, variable speed drive ATV320 1.1 kW 200...240 V - single phase - line choke - 1 per drive, variable speed drive ATV320 1.5 kW 200...240 V - single phase - line choke - 1 per drive, variable speed drive ATV320 2.2 kW 200...240 V - single phase - line choke - 1 per drive
    Reach Free ShvcYes
    China Rohs RegulationX
    Mercury FreeYes
    Packaging Made With Recycled CardboardNo
    Reach Free Of SvhcYes

    General Attributes

    Phase
    single phase
    Range Of Product
    Altivar
    Product Or Component Typeline choke

    ETIM

    ETIM 8
    EC002563
    ETIM 9EC002563

    Contractual Warranty Attributes

    Warranty Period
    18 months
    Warranty18 months
