Schneider Electric GV2G345 Linergy FT Comb Busbar 63A 3 Tap-Offs 45 mm Pitch

MPN: GV2G345
PPN: SCH-GV2G345

If you can't find the product or are unsure which one you need, please use the Product Selector tool below

$47.52

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

TeSys GV busbar set, 3 phases, 63A/690V, for the upstream parallel wiring of groups of motor starters composed of GV2 motor circuit breakers or LS1D32 fuse carriers. For use with screw clamp terminal devices, it is composed of 3 tap-off outlets for the paralleling of 3 devices with a pitch of 45mm. The use of a terminal block GV1G09 or GV2G05 is recommended to supply the busbar sets (to be ordered separately).

Features

Featuring a dedicated 3-tap branch design with 45mm spacing, this busbar link enables commercial panel builders to parallel-connect up to five TeSys Deca GV2 manual motor starters or protectors simultaneously. This multi-device grouping maximizes space efficiency inside compact automation enclosures and simplifies line-side branch circuit distribution.
Engineered with a robust 63-Amp current capacity and an insulation rating of 690V AC, this busbar effortlessly withstands the massive combined inrush currents of multiple inductive loads. It ensures cool, low-resistance electrical distribution across your entire motor control lineup, preventing heat-induced nuisance trips and localized terminal degradation.
This busbar features a precise 45mm center-to-center pitch that perfectly matches the physical width of standard GV2ME and GV2P manual starter frames, with or without attached side-mount auxiliary blocks. This engineered mechanical alignment guarantees clean, modular rows, eliminating the need to custom-bend jumper wires or waste precious DIN rail real estate.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Brazil, France, United Kingdom, India, Romania, United States

Important Information Attributes

Persona Type Ids	EU, LC, OM, OM8, PB, SC
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Connection Pitch	45 mm, 45 mm
Certificate Agency	CE, cULus
Local Publishable Date	2026-07-07
Stocking Flag	N
Serviceability	No
Field Service Division	PPIBS
Weee Product Category	5
Eoli Availability Display	Yes
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	No
Tier Id	1
Function Option Id	STANDARD
Product Kit Identifier	N
Device Short Name	GV2G
Fixing Mode	terminals
Number Of Tap Offs	3
Product Name	FT
Range	Linergy
Sustainable Packaging	Yes
Pep Code	ENVPEP2207006EN
[Ith] Conventional Free Air Thermal Current	63 A
Accessory / Separate Part Category	connection accessory
Nbr. Of Units In Pkg.	1
Take-back	No
Customs Code	8536908585

Persona Type Names	End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician
Market Segmentation	Commercial, Industrial
Range Of Product	TeSys GV2, TeSys fuse-disconnector, TeSys U, TeSys K, TeSys Deca
Local Data Status	Publishable
Return Indicator	Y
Stock Policy	2
Traceability	No
Weee Scope	In
Scope Perimeter	At least in Europe
End Of Life Doc Ref	ENVEOLI2207006
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	Yes
Rohs Eur Conformity Date	2542
China Rohs In Scope	No
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Compatibility Code	GV2G
Energy Efficiency Optimized	False
Number Of Poles	3P
Product Availability	Stock - Normally stocked in distribution facility
Product Or Component Type	comb busbar
Returnability	Yes
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Width Nominal	134 mm
[Ui] Rated Insulation Voltage	690 V
Number Of Tap-offs	3
Package Weight(Lbs)	58.000 g
Warranty (In Months)	18

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Reach Free Shvc	Yes
Toxic Heavy Metal Free	Yes
Circularity Profile	ENVEOLI2207006
Eu Rohs Directive	Compliant
Packaging Without Single Use Plastic	No
Reach Regulation	Free of Substances of Very High Concern above the threshold

Take Back	No
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Environmental Disclosure	ENVPEP2207006EN
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes
Pep Code	ENVPEP2207006EN
