Hubbell Wiring Device-Kellems HBL2310ST EdgeConnect™ Twist-Lock® Receptacle 20A 125V L5-20R, Black, Spring Termination
Hubbell Wiring Device-Kellems HBL2310ST EdgeConnect™ Twist-Lock® Receptacle 20A 125V L5-20R, Black, Spring Termination
- MPN: HBL2310ST
- UPC: 783585569543
- PPN: HBL-HBL2310ST
- UNSPSC: 39121406
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To view product inventory
CAD$39.94/ EA
Description
20A, 125V EdgeConnect™ Twist-Lock® Receptacle with Spring Termination
Features
- Faster termination time
- No need for screwdriver and torque wrench
- Spring Termination eliminates strand relaxation
- High-impact, abuse-resistant nylon face
- Face color coding by voltage facilitates locating and mating of proper devices
- Twist-Lock Receptacle with Spring Termination
Specifications
Specifications
- Country of Origin
- China
- Dimensions
- 3.28 in x 1.70 in x 1.47 in
- Industry Standard(s)
- UL Listed To UL 498;CSA Certified to Specification C22.2 No. 42;WR Rating
- Application
- Heavy Duty Industrial
- Connection
- Spring Termination
- Environmental Conditions
- Indoor Dry unless protected by additional means
- NEMA Rating
- L5-20R
- Number of Wires
- 3
- Size
- 3.28 in x 1.70 in x 1.47 in
- Standard
- UL Listed To UL 498;CSA Certified to Specification C22.2 No. 42;WR Rating
- Voltage Rating
- 125 V
- Voltage Rating Description
- 125 V
- General Literature Asset 1 Display Text
- EdgeConnect™ Technology
- General Literature Asset 3 Display Text
- EdgeConnect™ Technology FAQ
- Nema Rating
- L5-20R
- Number Of Wires
- 3
- Freight Class Code
- 06168002
- Image Actual Or Representative
- A
- Sub Class Code
- A08A110
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 15.000 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 50
- Pallet - GTIN - Package
- 70783585569542
- Pallet Length
- 48.000 in
- Pallet Width
- 40.000 in
Current / Amperage Rating20 A
Height1.47 in
Length3.28 in
ColorBlack
Dielectric StrengthWithstands 2,000V Minimum
MountingScrew Mount
Number of Poles2
PhaseSingle Phase
Special FeaturesTwist-Lock Receptacle with Spring Termination
Temperature RatingMaximum Continuous 75°C; Minimum -40°C (w/o impact)
Wire Size14 AWG - 10 AWG solid, 14 AWG - 8 AWG stranded (including compact stranded)
Width1.70 in
General Literature Asset 2 Display TextHealthcare Product Solutions
Mounting TypeScrew Mount
Number Of Poles2
Class CodeA08
Harmonization Code8536698000
MSDS FlagNo
MaterialNylon
BOX SIZE7.600x12.500x8.700 (in)
Carton - Number of Sub Packs50
Carton - SCC-14 Next Lower Level Sub Pack00783585569543
Case Weight4.979 lb.
Pallet Height45.600 in
Pallet Weight999.600 lb.
