Bryant CS6365 Industrial Male Plug 50A 125/250V 3-Pole 4-Wire Screw Terminal 6.38 Inch x 2.56 Inch
- MPN: CS6365
- UPC: 781786611795
- PPN: HBL-CS6365
- UNSPSC: 39121402
CAD
$255.06
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Locking Devices, Industrial, Male Plug, 50A 125/250V, 3-Pole 4-Wire Grounding, Non-NEMA, Screw Terminal, Heavy Duty Black
Features
- Tough nylon housing offers better impact qualities
- Stainless steel shroud restricts mismating with the wrong device
- Thermoplastic polyester interior provides heat resistance and impact strength
- Standard Product
Documentation & Downloads
Specifications
Key Specifications
- Number of Poles
- 3-Pole
- Size
- 6.38 in x 2.56 in x 2.56 in
- Country of Origin
- United States
- Dimensions
- 6.38 in x 2.56 in x 2.56 in
- Length
- 6.38 in
- Voltage Rating Description
- 125/250 VAC
- Amperage Rating
- 50 A
- Connectivity
- Screw Terminals
- Display Size
- Standard Sized
- Number Of Poles
- 3-Pole
- Phase
- Single Phase
- Type
- Plugs
- Class Code
- A08
- Freight Class Code
- 06168002
- Image Actual Or Representative
- A
- Sub Class Code
- A08A171
- Cord Diameter
- 0.830-1.250 in
- Material
- Composite
- BOX SIZE
- 8.200x12.500x9.100 (in)
- Carton - Number of Sub Packs
- 10
- Carton - SCC-14 Next Lower Level Sub Pack
- 781786611795
- Each - Pack Description
- Each
Number of Wires4-Wire
Special FeaturesStandard Product
ColorBlack
Height2.56 in
Voltage Rating125/250 VAC
Width2.56 in
ApplicationExtra Heavy Duty Industrial
Cord TypeAll Listed Portables
Environmental ConditionsIndoor Dry Unless Protected By Additional Means
Number Of Wires4-Wire
StyleExtra Heavy Duty
Wire Size#8 AWG to #4 AWG
Description - InvoiceLKG PLUG, 3P4W, 50A 125/250V
Harmonization Code8536694020
MSDS FlagNo
Material - Mounting HardwareCord Mounted
Current Rating50 A
Base Unit of MeasureEA
Carton - Gross Weight per Pack13.35 lb.
Carton - Pack DescriptionCarton
Carton - Total Units10 EA
Lowest Level UOMEach
Certifications
- EU RoHS Indicator
- Yes
