Square D QHB225 Mini Circuit Breaker 25A 2 Pole 120/240VAC 65kA Bolt-On Mount
Square D QHB225 Mini Circuit Breaker 25A 2 Pole 120/240VAC 65kA Bolt-On Mount
- MPN: QHB225
- UPC: 785901362326
- PPN: SCH-QHB225
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$372.88/ EA
Description
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 25A at 120/240VAC. This unit provides 65kA breaking capacity and bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
Specifications
- Current Rating
- 25 A
- Breaking Capacity
- 65 kA
- Mounting Type
- Bolt-on
- Height
- 76 mm (2.99 in.)
- Wire Size
- AWG 14...AWG 8 copper or aluminum
- Certifications
- UL Listed, CSA Certified
- Circuit Breaker Type
- Standard
- Electrical Connection
- Pressure plate
- Mercury Free
- Yes
- Reach Regulation
- Contains SVHC above threshold
- Net Weight
- 0.277 kg
- Warranty
- 18 months
Voltage120/240 V AC
Number of Poles2P
Width38 mm (1.50 in.)
Depth74 mm (2.91 in.)
Tightening Torque4.6 N.m (40.7 lbf.in)
Ambient Temperature Rating40 °C (104 °F)
Circuit Breaker ApplicationHACR rated
Toxic Heavy Metal FreeYes
RoHS ComplianceCompliant with Exemptions, Halogen free product, RoHS Exemption Yes
Sustainable Offer StatusGreen Premium product
Range of ProductQO
