Square D T36FN13G7 TeSys N Motor Starter 135A 100HP 3 Phase NEMA Size 4 120V AC
Square D T36FN13G7 TeSys N Motor Starter 135A 100HP 3 Phase NEMA Size 4 120V AC
- MPN: T36FN13G7
- UPC: 785901084969
- PPN: SCH-T36FN13G7
- UNSPSC: 39121521
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Description
Designed for robust performance in demanding industrial applications, this motor starter from Schneider Electric is a part of the TeSys N range, offering a reliable solution for controlling three-phase motors. With a line-rated current of 135A and capable of handling up to 100 horsepower at 575VAC, it ensures efficient operation while adhering to strict safety standards, as evidenced by its UL and CSA certifications. The solid-state thermal overload protection, along with a common control circuit, enhances the starter's reliability, making it an essential component for any automation and control system. Please note the product is open device rated and comes with a warning regarding potential exposure to chemicals, reflecting Schneider Electric's commitment to transparency and safety in their manufacturing processes.
Features
- Flexible with four overload relays types
- Customizable with hundreds of combinations
- Streamline installation, wiring, maintenance and field modifications
- Reliable build for long mechanical life and electrical endurance
- Ideal for use in construction, industrial markets, building automation
Specifications
Conformance Attributes
- Product Certifications
- UL Listed, CSA
Complementary Attributes
- Rated Power In HP
- 40 HP 200 V AC, 50 HP 230 V AC, 100 HP 460 V AC, 100 HP 575 V AC
- Line Rated Current
- 135 A
Control Circuitcommon control circuit
Important Information Attributes
- Persona Type Ids
- EU, LC, OM, OM8, PB, SC
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Local Data Status
- Publishable
- Legacy WEEE Scope
- In
- ROHS EUR In Scope
- Yes
- ROHS EUR Full Compliance Status
- Compliant with Exemptions
- China ROHS In Scope
- No
- Without Single Use Plastic
- No
- Return Indicator
- N
- Function Option
- Standard
- Electrical Connection
- lugs
- Motor Starter Type
- non reversing
- Phase
- 3 phase
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Range Of Product
- TeSys N
- Sustainable Packaging
- No
- Uc Control Circuit Voltage2
- 120 V AC
- Medium Desc
- Motor starter, TeSys N, nonreversing, Size 4, 135A, 3 pole, 100 HP at 575V, pre-assembled with Motor Logic SSOLR, 120VAC 60Hz coil
- Product Kit Identifier
- N
- Uc Control Circuit Voltage5
- 120 V AC
Persona Type NamesEnd User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician
Market SegmentationCommercial, Industrial
Local Publishable Date2026-02-13
Scope PerimeterOutside of Europe
ROHS EUR StatusCompliant with Exemptions
ROHS EUR Full Compliance Status IdCOMPLIANT_WITH_EXEMPTIONS
With Recycled CardboardNo
Product Contributes To Saved And Avoided EmissionsNo
Function Option IdSTANDARD
Control Circuitcommon control circuit
Energy Efficiency OptimizedFalse
Package Weight Lbs6.709 kg
Poles Description3P
Product Or Component Typestarter
ReturnabilityNo
Thermal Overload Typesolid state Motor Logic class 10/20 45-135 A
Ue Rated Operational Voltage2600 V AC
Stocking FlagY
Global Commercial StatusCommercialised
Ue Rated Operational Voltage5600 V AC
Environment Attributes Main
- China ROHS Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- ROHS Exemption Information
- Yes
- Reach Free SHVC
- Yes
- Mercury Free
- Yes
- Nema Size
- 4
- Packaging Without Single Use Plastic
- No
EU ROHS DirectiveCompliant By Exemption , Compliant with Exemptions
Take BackNo
Recycled Metal Content At Cr Level0 %
Nema Degree Of Protectionnot rated (open device)
Packaging Made With Recycled CardboardNo
Reach Free Of SVHCYes
General Attributes
- Phase
- 3 phase
- Range Of Product
- TeSys N
Product Or Component Typestarter
