Dragon Tooth

Dragon Tooth 22R081 RING TERM CU 24-15 AWG NO8 STUD

RING TERM CU 24-15 AWG NO8 STUD
  • MPN: 22R081
  • UPC: 786210811352
  • PPN: T-B-22R081
  • UNSPSC: 39121432

Spec sheet

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$0.82/ EA

Description

Insulation Piercing Magnet Wire Ring Terminal, Length .78 Inches, Width .30 Inches, Length of Teeth .32 Inches, Width of Teeth .16 Inches, Stud Size 8, Wire Range #24 AWG - #15 AWG 404 Circular Mil Area - 4,110 Circular Mil Area, Copper Alloy, Tin Plated

Specifications

Additional Information

Application
For aluminum to copper, aluminum to aluminum or copper to copper magnet wire connections.
Effective Date
19800612
Product Name
ELECTRICAL TERMINAL
Special Functions
Designed to penetrate magnet wire insulation during application, eliminating the need for stripping, brazing, welding or other methods of joining magnet wire.
Sub Brand / Label
Dragon Tooth
Brand / LabelSta-Kon
MaterialCopper
Product TypeRing Terminal
StandardsUL E9809

Classifications

WEEE Category
Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4603 >> Electrical terminals

Ordering

Country of Origin
United States (US)
Selling Unit of Measureeach
