Schneider Electric XENC1141 Spring Return Contact Block 2 NC Front Mounting 30-40 mm Centers
Schneider Electric XENC1141 Spring Return Contact Block 2 NC Front Mounting 30-40 mm Centers
- MPN: XENC1141
- PPN: SCH-XENC1141
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$63.55/ EA
Description
This Harmony XENC1141 is a spring return contact block 2 NC front mounting, 30 or 40mm centres. It is part of the range Harmony XAC pendant control stations for diameter 22mm plastic signaling units. It is designed for single speed applications.
Specifications
Environment
- Ambient Air Temperature For Operation
- -25-70 °C
- Standards
- CSA C22.2 No 14 || IEC 60947-5-1 || EN 60947-5-1
- Vibration Resistance
- 15 gn 10-500 Hz)IEC 60068-2-6
Ambient Air Temperature For Storage-40-70 °C
Shock Resistance100 gn IEC 60068-2-27
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- China Rohs Regulation
- X
- Mercury Free
- Yes
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Reach Free Of Svhc
- Yes
Rohs Exemption InformationYes
Toxic Heavy Metal FreeYes
Reach RegulationFree of Substances of Very High Concern above the threshold
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Complementary
- Terminal Identifier
- (13-14)NO || (11-12)NC
- Terminals Description Iso N°1
- (21-22)NC || (11-12)NC
- Rated Operational Power In Va
- 140 VA AC-15 1000000 cycles 60 cyc/mn 24 V 50/60 Hz 0.5 inductive || 385 VA AC-15 1000000 cycles 60 cyc/mn 48 V 50/60 Hz 0.5 inductive || 455 VA AC-15 1000000 cycles 60 cyc/mn 230 V 50/60 Hz 0.5 inductive || 525 VA AC-15 1000000 cycles 60 cyc/mn 127 V 50/60 Hz 0.5 inductive
- Mechanical Durability
- 1000000 cycles
- Short-Circuit Protection
- 10 A fuse protection cartridge gG
- Net Weight
- 0.02 kg
- [Uimp] Rated Impulse Withstand Voltage
- 6 kV IEC 60947-1
Connections - Terminalsscrew clamp terminals, 1 x 2.5 mm² with or without cable end || screw clamp terminals, 2 x 1.5 mm² with or without cable end
[Ui] Rated Insulation Voltage500 V 3)IEC 60947-1
Maximum Resistance Across Terminals25 MOhm
[Ithe] Conventional Enclosed Thermal Current10 A
Contact Code DesignationA300 AC-15, Ue = 240 V, Ie = 3 A IEC 60947-5-1 appendix A || Q300 DC-13, Ue = 250 V, Ie = 0.27 A IEC 60947-5-1 appendix A
Rated Operational Power In W42 W DC-13 1000000 cycles 60 cyc/mn 120 V 0.5 inductive IEC 60947-5-1 appendix C || 45 W DC-13 1000000 cycles 60 cyc/mn 48 V 0.5 inductive IEC 60947-5-1 appendix C || 60 W DC-13 1000000 cycles 60 cyc/mn 24 V 0.5 inductive IEC 60947-5-1 appendix C
Specifications
- Mounting Of Block
- front mounting
- Range Of Product
- Harmony XAC
- Mechanical Interlocking
- without mechanical interlock
- Contact Block Type
- single
- Product Or Component Type
- contact block
- Component Name
- XENC
Contacts Type And Composition2 NC
Contact Operationslow-break
Type Of Operatorspring return
Electrical Circuit Typecontrol circuit
Contact Block Applicationsingle speed
Product CompatibilityXACM || XACB
