Telemecanique Sensors XUVU06M3NSNM8 Photoelectric sensors XU, ultrasonic sensor label fork 60x3, 12...24 V DC, NPN NO/NC connect M8
Telemecanique Sensors XUVU06M3NSNM8 Photoelectric sensors XU, ultrasonic sensor label fork 60x3, 12...24 V DC, NPN NO/NC connect M8
- MPN: XUVU06M3NSNM8
- PPN: TES-XUVU06M3NSNM8
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$895.30/ EA
Description
This product is part of the XU range, an offer of photoelectric sensors. This ultrasonic sensor has a fork design and a thru-beam detection system. This photoelectric sensor has a numeric potentiometer setting-up, 2 LEDs for output state, adjustment mode and keypad locking. With an accuracy of ±0.20mm at 120m/min. It is furnished with 4-pin M8 male connector for electrical connection and 4-wire 1 normally open or 1 normally closed programmable NPN solid state discrete output. It is a photoelectric sensor with a rated supply voltage of 12V to 24V DC with reverse polarity protection and a switching frequency of ≤1500Hz. It is an IP65 rated product. The enclosure is made of zinc alloy with PC lens. Its dimensions are 18mm (Width) x 47mm (Depth) x 92.5mm (Height) and weighs 0.13kg. It is ideal for material handling, packaging, labelling, assembly, lift, escalators or food and beverage industries. It is ideal for detection of transparent labels. This product is certified by CE and CULus.
Specifications
Environment
- Product Certifications
- CE || cULus
- Vibration Resistance
- 7 gn +/- 1.5 mm 10-55 Hz) IEC 60068-2-6
- Ambient Air Temperature For Storage
- -20-70 °C
Ambient Air Temperature For Operation5-55 °C
Shock Resistance30 gn 11 ms) IEC 60068-2-27
Ip Degree Of ProtectionIP65 IEC 60529
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Mercury FreeYes
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
Complementary
- Height
- 92.5 mm
- Maximum Delay Response
- 0.3 ms
- Status Led
- output state 1 LED yellow) || adjustment mode and keypad locking 1 LED red)
- Lens Material
- PC
- Net Weight
- 0.13 kg
- Minimum Distance Between Labels
- 2 mm
- Maximum Delay First Up
- 30 ms
- Minimum Label Length
- 2 mm
- Enclosure Material
- zinc alloy
- Output Type
- solid state
- Maximum Passing Speed Of Object
- 180 m/min
Switching Frequency<= 1500 Hz
Type Of Output Signaldiscrete
Setting-Upnumeric potentiometer
Maximum Voltage Drop<2 V closed state)
Accuracy+/- 0.20 mm 120 m/min
Maximum Delay Recovery0.3 ms
Supply Voltage Limits10-30 V DC
Switching Capacity In Ma<= 100 mA overload and short-circuit protection)
Width18 mm
Depth47 mm
[Us] Rated Supply Voltage12...24 V DC reverse polarity protection
Specifications
- Passage Width
- 3 mm
- Electrical Connection
- 1 male connector M8, 4 pins
- Discrete Output Function
- 1 NO or 1 NC programmable
- Passage Depth
- 69 mm
- Sensor Name
- XUV
- Wiring Technique
- 4-wire
- Product Specific Application
- detection of transparent labels
- Sensor Design
- fork
- Electronic Sensor Type
- photo-electric sensor
Type Of Settingwith
Discrete Output TypeNPN
Range Of ProductTelemecanique Photoelectric sensors XU
Emissionultrasonic
Materialmetal
Series NameApplication packaging
Detection Systemthru beam
Supply Circuit TypeDC
[Sn] Nominal Sensing Distance3-3 mm thru beam
