Tripp Lite B127F-1A1-SM-DD DisplayPort over Fiber Extender Kit - 4K, RS-232, IR, USB, Duplex Singlemode LC, 6.2 mi., TAA
Tripp Lite B127F-1A1-SM-DD DisplayPort over Fiber Extender Kit - 4K, RS-232, IR, USB, Duplex Singlemode LC, 6.2 mi., TAA
- MPN: B127F-1A1-SM-DD
- UPC: 037332239174
- PPN: TRP-B127F-1A1-SM-DD
Spec sheet
Available to Order
Company Stock:
0
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$1322.11/ EA
Description
DisplayPort over Fiber Extender Kit - 4K, RS-232, IR, USB, Duplex Singlemode LC, 6.2 mi., TAA
Features
- Delivers UHD picture quality at resolutions up to 3840 x 2160 (4K x 2K) @ 30 Hz
- Supports uncompressed DTS-HD, Dolby AC-3 and 8-channel LPCM digital audio
- Meets DisplayPort 1.2a standards, including 4:4:4 subsampling for HDR televisions
- Plug-and-play operation with no software required for easy, immediate installation
- 1-year limited warranty
- DisplayPort Extender for Digital Signage or Displaying Video in Schools or Trade Show Booths
- Transmits Crystal-Clear 4K DisplayPort Video with Multi-Channel Audio and 4:4:4 Color
- DIP Switches Extend Your Choice of USB, IR or RS-232 Signals
- Plug-and-Play Operation for Quick Setup and Immediate Use
- TAA-Compliant for GSA Schedule Purchases
Specifications
Features & Specifications
- Max Supported Video Resolution
- 4K x 2K (3840 x 2160) @30Hz
- HDMI Specification
- 2.0
- Audio Specification
- True uncompressed 8-channel LPCM, AC-3, DTS digital audio
- EDID Compatible
- Yes
- IR Remote Extension Support
- Yes
- Technology
- DisplayPort; HDMI; HDR
- Chroma Sub Sampling
- 4:4:4
Displayport Specification1.2a
HDCP Specification2.2
Driver RequiredNo
Power Over Cable (PoC) SupportNo
RS-232 Serial Extension SupportYes
Wavelength1310nm
Mode TypeSinglemode
Certifications
- Certifications
- Tested to CE, FCC, REACH, RoHS
Connections
- Side A - Connector 1
- (2) 3.5MM (FEMALE); MICRO-USB B (FEMALE)
- Side B - Connector 1
- (2) 3.5MM (FEMALE); (2) USB A (FEMALE)
Side A - Connector 2DISPLAYPORT (FEMALE); HDMI (FEMALE); LC DUPLEX (FEMALE)
Side B - Connector 2DISPLAYPORT (FEMALE); LC DUPLEX (FEMALE)
Physical
- Color
- Black
- Rackmountable
- Yes
- Receiver Unit Weight (lbs.)
- 0.5
- Transmitter Unit Weight (lbs.)
- 0.5
Material of ConstructionMetal
Receiver Unit Dimensions (hwd / in.)1.06 x 4.53 x 2.46
Transmitter Unit Dimensions (hwd / in.)1.06 x 4.53 x 2.46
Unit Packaging TypeBox
User Interface, Alerts & Controls
- LED Indicators
- Tx: x3 ORANGE (Link Indicator, Local, Signal Transmission), x1 Green (Power) RX: x1 Orange (Link Indicator), x1 Green (Power)
Input
- Voltage Compatibility (VAC)
- 100; 110; 120; 125; 127; 200; 208; 220; 230; 240
- External Power Supply Output Specs (V / A)
- 5V/2A
- External Power Supply DC Barrel Connector Specs
- OD: 5.5 x 2.1 x 7.5mm, Positive Pin, Negative Sleeve
- External Power Supply Certifications
- CCC; CE; FCC; GS; TUV; UL; cUL
External Power Supply Input Specs (V / Hz / A)100-240~50/60Hz, 0.35A
External Power Supply Cord Length (ft.)4.5
External Power Supply Plug(s)AS/NZS 3112 Australia; BS 1363 UK; CEE 7/16 Schuko; NEMA 1-15P North America
Environmental
- Operating Temperature Range
- 32 to 104°F (0 to 40°C)
- Relative Humidity
- 0% to 85% RH, Non-Condensing
Storage Temperature Range5 to 122°F (-15 to 50°C)
Overview
- UPC Code
- 037332239174
Special Features
- HDR Support
- Yes
Warranty
- Product Warranty Period (Worldwide)
- 1-year limited warranty
Downloads
