Tripp Lite B127F-1A1-MM-HH HDMI Fiber Extender Kit 4K @ 60 Hz, 985 ft, HDR, RS-232, USB
- MPN: B127F-1A1-MM-HH
- UPC: 037332239143
- PPN: TRP-B127F-1A1-MM-HH
CAD
$1998.77
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
HDMI Fiber Extender Kit 4K @ 60 Hz, 985 ft, HDR, RS-232, USB
Features
- Delivers UHD picture quality at resolutions up to 3840 x 2160 (4K x 2K) @ 60 Hz
- Supports uncompressed DTS-HD, Dolby AC-3 and 7.1-channel digital audio
- Meets HDMI 2.0 standards, including 4:4:4 subsampling for HDR televisions
- Supports High Dynamic Range (HDR) for richer contrast and expanded color accuracy
- Transmitter's local HDMI port supports multi-resolution technology
- Plug-and-play operation with no software required for easy, immediate installation
- 1-year limited warranty
- HDMI Extender for Digital Signage or Displaying Video in Schools or Trade Show Booths
- Transmits Crystal-Clear 4K HDMI Video with Multi-Channel Audio and 4:4:4 Color
- DIP Switches Extend Your Choice of USB, IR or RS-232 Signals
- Plug-and-Play Operation for Quick Setup and Immediate Use
- Local HDMI Port Allows Connection of an Optional Display
- TAA-Compliant for GSA Schedule Purchases
Documentation & Downloads
Specifications
Additional
- Max Video Resolution
- 3840 x 2160 (4K) @ 60Hz
- Audio Support
- True uncompressed 8-channel LPCM, AC-3, DTS digital audio
- HDCP Specification
- 2.2
- Power Supply Input
- 100-240V, 50/60Hz, 0.35A
- External Power Supply DC Barrel Connector
- OD: 5.5 x 2.1 x 7.5mm, Positive Pin, Negative Sleeve
- Transmitter Unit Dimensions
- 1.06 x 4.53 x 2.46 in
- Transmitter Unit Weight
- 0.5 lbs
- Wavelength
- 850 nm
- IR Remote Extension Support
- Yes
- HDR Support
- Yes
- Rackmountable
- Yes
- Storage Temperature Range
- 5 to 122 F (-15 to 50 C)
- Color
- Black
- Side A - Connector 2
- (2) HDMI (FEMALE); LC DUPLEX (FEMALE)
- Side B - Connector 2
- HDMI (FEMALE); LC DUPLEX (FEMALE)
- External Power Supply Certifications
- CCC; CE; FCC; GS; TUV; UL; cUL
- Certifications
- CE, FCC, REACH, RoHS
- LED Indicators
- Tx: 3 Orange (Link, Local, Signal), 1 Green (Power); Rx: 1 Orange (Link), 1 Green (Power)
Signal Range985 ft
HDMI Specification2.0
Voltage Compatibility100; 110; 120; 125; 127; 200; 208; 220; 230; 240 VAC
Power Supply Output5V 2A
Receiver Unit Dimensions1.06 x 4.53 x 2.46 in
Receiver Unit Weight0.5 lbs
MaterialMetal
Mode TypeMultimode
RS-232 Serial Extension SupportYes
EDID CompatibleYes
Relative Humidity0% to 85% RH, Non-Condensing
Operating Temperature Range32 to 104 F (0 to 40 C)
Side A - Connector 1(2) 3.5MM (FEMALE); MICRO-USB B (FEMALE)
Side B - Connector 1(2) 3.5MM (FEMALE); (2) USB A (FEMALE)
Power Over Cable (PoC) SupportNo
External Power Supply Plug(s)AS/NZS 3112 Australia; BS 1363 UK; CEE 7/16 Schuko; NEMA 1-15P North America
Driver RequiredNo
