Schneider Electric LC1D65T6 TeSys Deca Contactor 3 Pole 65A 480V AC 60Hz
- MPN: LC1D65T6
- PPN: SCH-LC1D65T6
CAD
$506.98
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
The Schneider Electric LC1D65T6 TeSys Deca Contactor is engineered for high-performance operation, suitable for applications requiring reliable control of electrical loads. With a capacity of 65A and compatibility with 480V AC at 60Hz, this three-pole contactor is designed to efficiently handle significant power demands in automation and control systems. Its robust construction ensures durability in industrial environments, making it an ideal choice for professionals seeking dependable starters and contactors for their automation needs.
Documentation & Downloads
Specifications
Additional
- Rated Operational Current
- 80 A AC-1 at 440 V, 65 A AC-3 at 440 V power circuit (at <60 °C)
- Maximum Horsepower Rating
- 50 Hp at 460/480 V AC 60 Hz
- Rated Operational Voltage
- power circuit <= 690 V AC 25...400 Hz
- Maximum Operating Rate
- 3600 cycles/hour at 60 °C
- Rated Breaking Capacity
- 1000 A at 440 V power circuit
- Conventional Free Air Thermal Current
- 80 A power circuit; 10 A control circuit (at 60 °C)
- Power Dissipation per Pole
- 6.4 W AC-1
- Rated Impulse Withstand Voltage
- 8 kV IEC 60947
- Mechanical Durability
- 6,000,000 cycles
- Minimum Switching Current
- 5 mA control circuit
- Pole Contact Composition
- 3 NO
- Poles
- 3 Pole
- Connection Type
- Screw clamp terminals; connector terminals
- Dimensions (HxWxD)
- 5.00 in x 2.95 in x 4.69 in (127 x 75 x 119 mm)
- Material
- Not specified
- Flame Retardance
- V1 UL 94
- IP Degree of Protection
- IP2X IEC 60529
- Ambient Air Temperature
- -5 to 60 °C, -40 to 70 °C at Uc
- RoHS Compliance
- Compliant
- Mercury Free
- Yes
- Reach Compliance
- Free of Substances of Very High Concern above threshold
- Standards
- UL 508, EN 60947-4-1, EN 60947-5-1, IEC 60947-4-1, CSA C22.2 No 14
- Brand
- LC1D (Compatibility code)
Motor Power30 kW at 440 V AC 50/60 Hz
Rated Insulation Voltage600 V control & power circuit CSA/UL; 690 V IEC 60947-1
Control Circuit Voltage480 V AC 60 Hz
Rated Making Capacity140 A AC control circuit; 1000 A power circuit at 440 V
Associated Fuse Rating10 A gG control circuit; 125 A gG power circuit (<= 690 V)
Average Impedance1 mOhm at 80 A 50 Hz power circuit
Overvoltage CategoryIII
Safety Reliability LevelB10d = 1,369,863 cycles nominal load; 20,000,000 cycles mechanical load
Operating Time12-26 ms closing; 4-19 ms opening
Tightening TorqueControl circuit 1.2 N.m; Power circuit 5 N.m
Auxiliary Contact Composition1 NO + 1 NC
Terminal Cable Size Range1-35 mm² (varies by terminal and cable type)
Mounting TypePlate or rail
Net Weight1.4 kg (3.09 lb)
Fire Resistance850 °C IEC 60695-2-1
Mechanical RobustnessShocks: 10 Gn open, 15 Gn closed; Vibrations: 2-4 Gn
Climatic WithstandIACS E10 exposure to damp heat
Operating Altitude3000 m without derating
PVC FreeYes
Toxic Heavy Metal FreeYes
Product CertificationsCSA, BV, UL, GL, CCC, GOST, LROS (pending), DNV, RINA, UKCA
Country of OriginCzech Republic
