Schneider Electric RSLZRA1 Harmony Relay Socket, LED Indicator, 12-24V AC/DC, 6.2mm Width

MPN: RSLZRA1
PPN: SCH-RSLZRA1
UNSPSC: 39122326

If you can't find the product or are unsure which one you need, please use the Product Selector tool below

$13.37

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

"This Harmony RSLZ plug-in relay socket has a coil control voltage of 12 - 24V AC/DC." "It has large choice of number of contacts for high rated current use." "It also offers LED indicator and protection circuit." "It helps to reduce the size of enclosures and increase machine reliability, you can mount nearly everywhere." "One of the slimiest socket on the market, with 6.2mm width, it can be installed nearly anywhere." "Workability for hard-wired logic automated systems to complement the functions of industrial programmable logic controllers (PLCs)." "Status display with LED, clearly signal both in the day and night."

Features

Compatible with plug in control relay Schneider Electric
It is flexibility design for space-saving
Easy installation and connect to the relay from its socket
Workablity for hard-wired logic automated systems to complement the functions of industrial PLCs

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	China

Weight	23 g

Physical Attributes

Cad Overall Depth	101 mm
Cad Overall Width	6.2 mm

Cad Overall Height	78.6 mm

Complementary Attributes

Rated Operational Voltage Limits	21.6...28.8 V, 11.4...14.4 V
Ue Rated Operational Voltage	< 300 V AC, < 300 V AC< 300 V AC, < 300 V AC
Uimp Rated Impulse Withstand Voltage	3.6 kV

Uc Control Circuit Voltage	12 V, 24 V
Line Rated Current	6 A

Important Information Attributes

Persona Type Ids	BM9, EU, LC, OM, OM8, PB, SC, SI, VR
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Switching Voltage	12 V AC/DC, 24 V AC/DC
Certificate Agency	GOST, CSA
Carbon Footprint Of The End Of Life Phase C1 To C4	0 kg CO2 eq., 0.0058696229
Carbon Footprint Of The Manufacturing Phase A1 To A3	0.7 kg CO2 eq., 0.7178809598
Local Data Status	Publishable
Return Indicator	Y
Weee Product Category	5
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	1930
China Rohs In Scope	Yes
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Clamping Force	10-40 N
Contact Terminal Arrangement	separate
Device Short Name	RSLZ
Group Of Product	RSL_SPRING_TERS_12-24
Overvoltage Category	III
Product Or Component Type	socket
Returnability	Yes
Shape Of Pin	flat
Sustainable Packaging	Yes
Database Version	2018-09
Nbr. Of Units In Pkg.	1
Ith Conventional Free Air Thermal Current	6 A
Functional Unit Description	To control a circuit by a low-power signal with complete electrical isolation between control and controlled circuits, or where several circuits must be controlled by one signal during 20 years with a 100% use rate, in compliance with French standards.
Functional Unit Unit	unité (unit)
Recyclability Potential In %	70

Persona Type Names	Charge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner
Market Segmentation	Commercial, Industrial
Connections Terminals	spring terminals, spring terminals, 1 x 0.2...1 x 1.5 mm² 24 AWG...16 AWG) flexible with cable endspring terminals, 1 x 0.2...1 x 1.5 mm² 24 AWG...16 AWG) solid without cable end
Carbon Footprint Of The Distribution Phase A4	0.0029674945, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase A5	0.0001390679, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase B2 B3 B4 B6	kg CO2 eq., 0
Local Publishable Date	2026-08-10
Weee Scope	Out
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	Yes
Tier Id	1
Function Option Id	STANDARD
Product Kit Identifier	N
Compatibility Code	RSLZ
Contacts Type And Composition	1 C/O
Fixing Mode	plastic compression spring (35 mm symmetrical DIN rail)
Marking	CE
Product Availability	Stock - Normally stocked in distribution facility
Range Of Product	Harmony Electromechanical Relays
Sale Per Indivisible Quantity	10
Software Version	EIME v5.7.0.4
Total Lifecycle Carbon Footprint	0.7 kg CO2 eq.
Data Source	extrapolated product
Customs Code	8536698000
Warranty In Months	18
Functional Unit Quantity	1
Reference Lifetime In Y	20

Environment Attributes Main

Ambient Air Temperature For Operation	-40-70 °C, -40-70 °C
Product Compatibility	plug-in relay RSL 1 C/O 12 V DC, plug-in relay RSL 1 C/O 24 V DC
Reach Free Shvc	Yes
China Rohs Regulation	X
Mercury Free	Yes
Environmental Disclosure	ENVPEP2502015EN
Ip Degree Of Protection	IP20 conforming to IEC 60529
Packaging Without Single Use Plastic	Yes
Reach Regulation	Free of Substances of Very High Concern above the threshold
Pep Verification Date	2018-09-01
Psr Version	PSR-0005-ed2-EN-2016 03 29

Ambient Air Temperature For Storage	-40-85 °C, -40-85 °C
Take Back	No
Recycled Metal Content At Cr Level	0 %
Toxic Heavy Metal Free	Yes
Carbon Footprint	0.7268571452
Eu Rohs Directive	Compliant
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes
Pep Code	ENVPEP2502015EN
Pcr Version	PCR-ed3-EN-2015 04 02
Type Of Verification For The Pep	Independent internal review
