Hubbell Wiring Device-Kellems HBLDS30TACNK Industrial Grade Motor Disconnect Switch 3 Pole 30A 600V AC IP69k NEMA Type 4X
- MPN: HBLDS30TACNK
- UPC: 783585763477
- PPN: HBL-HBLDS30TACNK
- UNSPSC: 39122205
CAD
$701.00
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Industrial Grade, Motor Disconnect, Unfused, 3 Pole, 30A 600V AC, Screw Terminals, IP69k, NEMA Type 4X, 12 Non-Metallic Sloped Top Enclosure for Top Feed Applications, Aux Contact, No KO, cULus, NSF, CE, UL 508 / UL 60947-4-1A
Features
- Constructed from corrosion and impact resistant UV stabilized non-metallic material
- Rounded sloped top enclosure has a single flat for top feed applications and supports best practices in hygienic design by shedding dirt and debris
- IP69k and Type 4X,12K water ingress protection and Certified by NSF for hygiene in food processing applications
- Highly visible red handle can be locked in the OFF position as a method of compliance with OSHA Lockout/Tagout requirements
- Product rating are permanently laser-marked and will not wash off
- Factory installed HBLAC1 auxiliary contact is "Break After Main Break", 1 set of N/O contacts, 1 set of N/C contacts
Specifications
Additional
- Amperage
- 30A
- Poles
- 3 Pole
- Dielectric Strength
- Withstands 3000V AC minimum
- Operating Cycles
- 10,000 Cycles Minimum
- Enclosure Type
- IP69k and UL Type 4X, 12
- Width
- 5.500 in
- Hub Size
- 3/4 in
- Wire Size Range
- #14 AWG to #8 AWG
- Style
- Heavy Duty
- Country of Origin
- PL
- Series
- Non-Fused
Voltage600V AC
Horsepower Maximum15 HP
Operating Temperature-40b0C to 75b0C continuous without impact
Ingress ProtectionIP69k, NEMA Type 4X, 12
Mounting MethodExternal fully adjustable feet
Height4.12 in
Weight2.8 lb
Material - Mounting HardwareStainless Steel Screw Mounting
ColorGray
CertificationscULus Listed, NSF, CE, UL 508, UL 60947-4-1A
Auxiliary Contact1 set N/O, 1 set N/C, Break After Main Break
