Schneider Electric NSYTRP22AR Linergy TR Push-In Terminal Block, 2 Points, 2.5 mm2, Orange, Set of 50

MPN: NSYTRP22AR
PPN: SCH-NSYTRP22AR

If you can't find the product or are unsure which one you need, please use the Product Selector tool below

$3.60

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

The Schneider Electric Linergy TR Push-In Terminal Block is engineered for seamless integration into various automation and control applications. Designed with precision, each block features two points with a capacity of 2.5 mm2, offering reliable connectivity for your electrical projects. Available in an eye-catching orange color, these terminal blocks come in a convenient set of 50, making them an ideal choice for both large and small-scale installations. Their user-friendly push-in design promotes efficient wiring while ensuring safety and performance in demanding environments.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Brazil, China, Germany, France

Physical Attributes

Color	Orange

Wire Stripping Length	10 mm

Complementary Attributes

Line Rated Current	24-24 A EN/IEC 60947-7-120-20 A CSA, 20-20 A UL

Important Information Attributes

Persona Type Ids	EU, LC, OM, OM8, PB, SI
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Cable Cross Section	0.2-2.5 mm², solid without cable end0.14-2.5 mm², flexible without cable end0.14-4 mm², solid with cable end, 0.2-2.5 mm², flexible with cable end
Dielectric Loss	0.01 at 1 MHz IEC 60250, 0.01 at 1 MHz VDE 0303-T4
Resistivity	10000 MΩ.m IEC 60093, 10000 MΩ.m VDE 0303-T30
Certificate Agency	CSA, GL, UL, VDE
Connections - Terminals	1 x push-in upstream, 1 x push-in downstream
Carbon Footprint Of The End-of-life Phase [C1 To C4]	0 kg CO2 eq., 0.015452988
Carbon Footprint Of The Manufacturing Phase [A1 To A3]	0 kg CO2 eq., 0.037306971
Local Data Status	Publishable
Return Indicator	Y
Stock Policy	2
Weee Applicability	Component
Weee Exclusion Rationale	Component not in scope – non independent function
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	Yes
Rohs Eur Conformity Date	2518
China Rohs In Scope	No
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	2
Function Option	Standard
Compatibility Code	terminal block
Device Short Name	TRP
Dielectric Strength	1000 V IEC 60243-1
Flame Retardance	V0 0.8 mm UL 94
Nominal Cross Section	2.5 mm²
Product Availability	Stock - Normally stocked in distribution facility
Product Or Component Type	terminal block
Range	Linergy
Returnability	Yes
Sustainable Packaging	Yes
Terminal Block Type	passthrough
Total Lifecycle Carbon Footprint	5 kg CO2 eq.
Database Version	2022-01
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent external review
Functional-unit Description	Connect during 20 years 2 clamping units between 2 or more wires with a rated connecting capacity 19 A, a rated cross-section 2.5 mm2, a rated voltage 550 V, a short-time withstand current 0.3 kA.
Functional-unit Unit	unit
Energy Model - Manufacturing [A1-a3]	Electricity Mix; Production mix; Low voltage; GE
Energy Model - Use [B6]	Electricity Mix; Production mix; Low voltage; UE-27
Recyclability Potential In %	33
Length Total	48.5 mm
Accessory / Separate Part Category	connection accessory
Nbr. Of Units In Pkg.	1
Silicone-free	Yes
Warranty (In Months)	18
Climate Change - Total ( Kg Co2 Eq.) Operational Energy Use [B6]	4.4787
Ecotoxicity (Fresh Water) (Ctue) Operational Energy Use [B6]	48.232
Total Use Of Primary Energy During The Life Cycle (Mj) Operational Energy Use [B6]	136.02
Use Of Non-renewable Primary Energy Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6]	114.1
Customs Code	8536904000

Persona Type Names	End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market Segmentation	Commercial, Industrial
Creep Resistance	500 CTI (> 400 kB) IEC 60093, 500 CTI (> 400 kB) VDE 0303-T30
Material	polyamide 6/6: insulating casecopper alloy: connector and screw, copper alloy: commoning linkchromium-nickel steel: spring
Surface Resistance	1000 GΩ IEC 60093, 1000 GΩ VDE 0303-T30
[Ue] Rated Operational Voltage	800 V EN/IEC 60947-7-1600 V CSA, 600 V UL
Carbon Footprint Of The Distribution Phase [A4]	0.0007846, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase [A5]	0.000708348, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase [B2 B3 B4 B6]	4 kg CO2 eq., 4.4787
Local Publishable Date	2026-06-27
Stocking Flag	N
Use Carbon Footprint	4.4787
Weee Scope	Out
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	Yes
Tier Id	2
Function Option Id	STANDARD
Product Kit Identifier	N
Connection Position	top
Dielectric Constant	3.7 at 1 MHz
Energy Efficiency Optimized	False
Mounting Mode	clip-on
Number Of Terminals	2
Product Name	Linergy TR
Quantity Per Set	set of 50
Range Of Product	Linergy
Software Version	v5.9.4
Terminal Block Level	1
Tool Type	connection without tooldisconnection flat screwdriver
Pep Code	ENVPEP2309019EN
Pep Verification Date	2023-12-03
Psr Version	PSR-0005-ed2-2016 03 29
Data Source	extrapolated product
Functional-unit Quantity	1
Reference Lifetime In Y	20
Energy Model - Installation [A5]	Electricity Mix; Production mix; Low voltage; UE-27
Energy Model - End Of Life [C1-c4]	Electricity Mix; Production mix; Low voltage; UE-27
Height Nominal	36.5 mm
Width Nominal	5.2 mm
Halogen-free Status	Halogen free plastic parts product
Package Weight(Lbs)	6.000 g
Take-back	No
Climate Change - Fossil Fuels ( Kg Co2 Eq.) Operational Energy Use [B6]	4.4727
Depletion Of Abiotic Resources - Fossil Fuels (Mj) Operational Energy Use [B6]	114.1
Ionizing Radiation Human Health (Kbq Of U235 Equiv.) Operational Energy Use [B6]	6.6592
Total Use Of Renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Operational Energy Use [B6]	21.911
Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6]	21.911

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Take Back	No
Halogene Performance	Halogen free plastic parts product
Toxic Heavy Metal Free	Yes
Silicon Free	Yes
Environmental Disclosure	ENVPEP2309019EN
Halogen Content Performance	Halogen free plastic parts product
Packaging Without Single Use Plastic	Yes
Reach Free Of Svhc	Yes
Pep Code	ENVPEP2309019EN
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent external review

Ambient Air Temperature For Operation	-40-130 °C IEC 60216-1, -40-130 °C IEC 60216-1, -40-130 °C VDE 0304-T21, -40-130 °C VDE 0304-T21-40-130 °C IEC 60216-1, -40-130 °C IEC 60216-1, -40-130 °C VDE 0304-T21
Reach Free Shvc	Yes
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Carbon Footprint	4.532952907
Eu Rohs Directive	Compliant
Packaging Made With Recycled Cardboard	Yes
Product Compatibility	Spacial enclosures
Reach Regulation	Free of Substances of Very High Concern above the threshold
Pep Verification Date	2023-12-03
Psr Version	PSR-0005-ed2-2016 03 29
