ABB

ABB 1SNA645019R0400 Boxed Interface Relay R600 24V AC/DC, 1 n/c Contact, IP20, 67.5mm Height

Boxed Interface Relay R600 24V AC/DC, 1 n/c Contact, IP20, 67.5mm Height
  • MPN: 1SNA645019R0400
  • UPC: 662019284484
  • PPN: ABB-1SNA645019R0400
  • UNSPSC: 39122331

Spec sheet

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$60.66/ EA

Description

The RB101R-24VUC is a boxed interface relay with screw terminals, which can be seemlessly snap-on mounted onto a DIN Rail. The relay is soldered into device housing, ensuring a high resistance against vibration.This relay operates with a 24 V AC/DC rated control supply voltage and has a 1 n/c (SPST) output with contacts rated at 250 V / 6 A. This 6mm wide boxed interface relay may be used for electrical isolation, amplification and signal matching and enables the switching of high currents on a small footprint. It has an integrated LED, which provides the visual indication of the energization of the relay coil and UL 94-V0 certified device housing, improving safety by providing high levels flame retardation. Jumper bars are available as accessories.

Specifications

Dimensions

Product Net Width
12 mm
Product Net Depth / Length
70 mm
Product Net Height67.5 mm
Product Net Weight0.04 kg

Technical

Function
Boxed interface relay R600
Rated Control Supply Voltage (Us)
24 V AC/DC
Output Signal
5 ... 250VAC / 60mA ... 6A
Degree of Protection
IP20
Sub-FunctionRelay with built in LED and RC circuit
Output1 n/c contact
Terminal TypeScrew Terminals
StandardsCAN/CSA C22.2 No.14IEC/EN 63000IEC/EN 60947-5-1UL 508

Classifications

Object Classification Code
K
eClass
V11.0 : 27371601
ETIM 9EC001437 - Switching relay
E-Number (Sweden)4001114

Environmental

RoHS Status
Following EU Directive 2011/65/EU

Ordering

Minimum Order Quantity
5 piece
Customs Tariff Number85364900
