Square D T36EN23G7 TeSys N Motor Starter, 90A, 50hp at 575VAC, NEMA Size 3
Square D T36EN23G7 TeSys N Motor Starter, 90A, 50hp at 575VAC, NEMA Size 3
- MPN: T36EN23G7
- PPN: SCH-T36EN23G7
- UNSPSC: 39121521
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Description
The TeSys N motor starter from Schneider Electric is engineered for robust performance in industrial applications, capable of handling a line rated current of 90A and designed for 3-phase systems. With a rated operational voltage of up to 600V AC and a reversing starter type, this device is ideal for controlling motors up to 50 horsepower at 575VAC. Its solid-state thermal overload protection ensures reliable operation, while the NEMA size 3 design provides compatibility with various installations. Additionally, this product is UL Listed and CSA certified, ensuring compliance with safety standards for your peace of mind.
Features
- Flexible with four overload relays types
- Customizable with hundreds of combinations
- Streamline installation, wiring, maintenance and field modifications
- Reliable build for long mechanical life and electrical endurance
- Ideal for use in construction, industrial markets, building automation
Specifications
Conformance Attributes
- Product Certifications
- UL Listed, CSA
Complementary Attributes
- Rated Power In HP
- 25 HP 200 V AC, 30 HP 230 V AC, 50 HP 460 V AC, 50 HP 575 V AC
- Line Rated Current
- 90 A
Control Circuitcommon control circuit
Important Information Attributes
- Persona Type Ids
- EU, LC, OM, OM8, PB, SC
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Local Data Status
- Publishable
- Legacy WEEE Scope
- In
- ROHS EUR In Scope
- Yes
- ROHS EUR Full Compliance Status
- Compliant with Exemptions
- China ROHS In Scope
- No
- Without Single Use Plastic
- No
- Return Indicator
- N
- Function Option
- Standard
- Electrical Connection
- lugs ordered separately
- Motor Starter Type
- reversing
- Phase
- 3 phase
- Product Availability
- Stock - Normally stocked in distribution facility
- Range Of Product
- TeSys N
- Sustainable Packaging
- No
- Uc Control Circuit Voltage2
- 120 V AC
- Medium Desc
- Starter, TeSys N, 90A, 1NO, 50HP at 575VAC, NEMA size 3
- Product Kit Identifier
- N
- Uc Control Circuit Voltage5
- 120 V AC
Persona Type NamesEnd User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician
Market SegmentationCommercial, Industrial
Local Publishable Date2026-02-13
Scope PerimeterOutside of Europe
ROHS EUR StatusCompliant with Exemptions
ROHS EUR Full Compliance Status IdCOMPLIANT_WITH_EXEMPTIONS
With Recycled CardboardNo
Product Contributes To Saved And Avoided EmissionsNo
Function Option IdSTANDARD
Control Circuitcommon control circuit
Energy Efficiency OptimizedFalse
Package Weight Lbs11.884 kg
Poles Description3P
Product Or Component Typestarter
ReturnabilityNo
Thermal Overload Typesolid state Motor Logic class 10/20 30-90 A
Ue Rated Operational Voltage2600 V AC
Stocking FlagY
Global Commercial StatusCommercialised
Ue Rated Operational Voltage5600 V AC
Environment Attributes Main
- China ROHS Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- ROHS Exemption Information
- Yes
- Recycled Metal Content At Cr Level
- 0 %
- Nema Degree Of Protection
- not rated (open device)
- Packaging Made With Recycled Cardboard
- No
EU ROHS DirectiveCompliant By Exemption , Compliant with Exemptions
Take BackNo
Mercury FreeYes
Nema Size3
Packaging Without Single Use PlasticNo
General Attributes
- Phase
- 3 phase
- Range Of Product
- TeSys N
Product Or Component Typestarter
