Schneider Electric LC2D50G7 Reversing Contactor 3P 50A AC-3 120V AC 60Hz
- MPN: LC2D50G7
- PPN: SCH-LC2D50G7
CAD
$1060.48
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
The Schneider Electric LC2D50G7 Reversing Contactor is an essential component for industrial automation and control applications, designed to efficiently manage motor control in demanding environments. With a robust 50A AC-3 rating, this contactor operates at 120V AC and 60Hz, providing reliable performance for both forward and reverse motor operation. Ideal for use in NEMA-rated applications, it ensures seamless switching and optimal performance, making it a crucial choice for panel builders and engineers seeking durability and precision in their control systems.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Czechia, France, United States
Depth142 mm
Complementary Attributes
- Irms Rated Making Capacity
- 140 A AC for control circuit conforming to IEC 60947-5-1900 A at 440 V for power circuit conforming to IEC 60947
- Maximum Operating Rate
- 3600 cyc/h 60 °C
- Minimum Switching Voltage
- 17 V for control circuit
Maximum Motor Phase Current50 A
Minimum Switching Current5 mA for control circuit
Rated Breaking Capacity900 A at 440 V for power circuit conforming to IEC 60947
Important Information Attributes
- Persona Type Ids
- EU, LC, OM, OM8, PB, SI
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Associated Fuse Rating
- 10 A gG for control circuit conforming to IEC 60947-5-1100 A gG at <= 690 V coordination type 1 for power circuit, 100 A gG at <= 690 V coordination type 2 for power circuit
- Inrush Power In Va
- 200-200 VA cos phi 0.75 (at 20 °C), 220-220 VA cos phi 0.75 (at 20 °C)
- Mounting Support
- plate, rail
- Utilisation Category
- AC-2, AC-3, AC-4
- Certificate Agency
- GL, UL, RINA, GOST, CSA, LROS (Lloyds register of shipping), CCC, DNV, BV, UKCA
- Connections - Terminals
- control circuit 2 1-4 mm²flexible without cable end, control circuit 2 1-4 mm²solid without cable endpower circuit 1 1-35 mm²flexible without cable end, power circuit 1 1-35 mm²solid without cable end, power circuit 2 1-25 mm²flexible with cable end, power circuit 2 1-25 mm²flexible without cable end, power circuit 2 1-25 mm²solid without cable end, power circuit 2 1-35 mm²flexible with cable end, power circuit 2 1-35 mm²flexible without cable end, power circuit 2 1-35 mm²solid without cable endcontrol circuit 1 1-4 mm²flexible with cable end, control circuit 1 1-4 mm²flexible without cable end, control circuit 1 1-4 mm²solid without cable end, control circuit 2 1-2.5 mm²flexible with cable end, power circuit 1 1-35 mm²flexible with cable end
- Non-overlap Time
- 1.5 ms on de-energisation between NC and NO contacts, 1.5 ms on energisation between NC and NO contacts
- Carbon Footprint Of The End-of-life Phase [C1 To C4]
- 5 kg CO2 eq., 4.516970098061568
- Carbon Footprint Of The Manufacturing Phase [A1 To A3]
- 12 kg CO2 eq., 12.107909753995546
- Local Data Status
- Publishable
- Return Indicator
- Y
- Stock Policy
- 2
- Serviceability
- No
- Field Service Division
- PPIBS
- Weee Scope
- In
- Scope Perimeter
- At least in Europe
- Reach Full Compliance Status
- Free of Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Free of Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant
- Rohs Eur Full Compliance Status
- Compliant
- China Rohs Label
- 1
- Without Single Use Plastic
- Yes
- Tier Id
- 1
- Function Option Id
- STANDARD
- Product Kit Identifier
- N
- Compatibility Code
- LC2D
- Device Short Name
- LC2D
- Flame Retardance
- V1 conforming to UL 94
- Mechanical Durability
- 6000000 cycles
- Operating Time
- 12...26 ms closing4...19 ms opening
- Pole Contact Composition
- 3 NO
- Product Or Component Type
- reversing contactor
- Returnability
- Yes
- Software Version
- v5.9.4
- Total Lifecycle Carbon Footprint
- 108 kg CO2 eq.
- Inf Motor Phase Current
- 50 A
- Database Version
- 2022-01
- Pcr Version
- PEP-PCR-ed4-2021 09 06
- Type Of Verification For The Pep
- Independent internal review
- Functional-unit Description
- Switch on and off during 20 years electrical power supply of a downstream installation with an electrical and/or mechanical control. The functional unit is characterized by a type 3P(3NO), a control circuit voltage 230V AC, a power circuit voltage 690V and a rated operational current 80A
- Functional-unit Unit
- unit
- Energy Consumption On Product Lifetime In Kwh
- 1362.18
- Energy Model - Installation [A5]
- Electricity Mix; Production mix; Low voltage; FR
- Energy Model - End Of Life [C1-c4]
- Electricity Mix; Production mix; Low voltage; FR
- Height Nominal
- 132 mm
- [Ith] Conventional Free Air Thermal Current
- 10 A (at 60 °C) for control circuit80 A (at 60 °C) for power circuit
- [Ue] Rated Operational Voltage
- power circuit <= 1000 V AC 25...400 Hz
- Rated Thermal Current (Ith)
- 80 A
- Package Weight(Lbs)
- 3.221 kg
- Warranty (In Months)
- 18
Persona Type NamesEnd User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market SegmentationCommercial, Industrial
Average Impedance- Ith 80 A 50 Hz for power circuit, - Ith 80 A 50 Hz for power circuit, - Ith 80 A 50 Hz for power circuit- Ith 80 A 50 Hz for power circuit, - Ith 80 A 50 Hz for power circuit, - Ith 80 A 50 Hz for power circuit
Insulation Resistance> 10 MOhm for control circuit, > 10 MOhm for control circuit> 10 MOhm for control circuit, > 10 MOhm for control circuit
Tightening Torquecontrol circuit 1.7 N.m 1-4 mm² flat Ø 6 mmcontrol circuit 1.7 N.m 1-4 mm² Philips No 2, control circuit 1.7 N.m 1-2.5 mm² flat Ø 6 mm, control circuit 1.7 N.m 1-2.5 mm² Philips No 2, power circuit 5 N.m 1-25 mm² hexagonal, power circuit 8 N.m 1-35 mm² hexagonal
Control Circuit Voltage120 V
[Ui] Rated Insulation Voltagepower circuit 600 V ULpower circuit 690 V IEC 60947-1control circuit 600 V CSA, control circuit 600 V UL, power circuit 600 V CSAcontrol circuit 690 V IEC 60947-1
Hold-in Power Consumption In Va26-26 VA 60 Hz cos phi 0.3 (at 20 °C), 20-20 VA 50 Hz cos phi 0.3 (at 20 °C)22-22 VA 60 Hz cos phi 0.3 (at 20 °C), 26-26 VA 50 Hz cos phi 0.3 (at 20 °C)
Carbon Footprint Of The Distribution Phase [A4]0.238856956586287, 0.2 kg CO2 eq.
Carbon Footprint Of The Installation Phase [A5]0.34247542195758524, 0.3 kg CO2 eq.
Carbon Footprint Of The Use Phase [B2 B3 B4 B6]91 kg CO2 eq., 91.01257246376808
Local Publishable Date2026-06-27
Stocking FlagN
Device TypeLV equipment - LV contactor
TraceabilityNo
Average Life Duration20 year(s)
Weee Product Category5
Eoli Availability DisplayNo need of specific recycling operations
Reach Full Compliance Status IdNOT_CONTAINING_SVHC
Rohs Eur In ScopeYes
Rohs Eur Conformity Date1926
China Rohs In ScopeNo
With Recycled CardboardYes
Product Contributes To Saved And Avoided EmissionsNo
Tier1
Function OptionStandard
Coil Technologywithout built-in bidirectional peak limiting diode suppressor
Contactor Applicationmotor control
Fire Resistance850 °C IEC 60695-2-1
Interlocking Typemechanical
Number Of Poles3P
Overvoltage CategoryIII
Product AvailabilityStock - Normally stocked in distribution facility
Range Of ProductTeSys Deca
Safety Reliability LevelB10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1
Sustainable PackagingYes
Weee LabelThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Pep CodeENVPEP1102005EN
Pep Verification Date2025-11-20
Psr VersionPSR-0005-ed2-2016 03 29
Data Sourceextrapolated product
Functional-unit Quantity1
Reference Lifetime In Y20
Energy Model - Manufacturing [A1-a3]Electricity Mix; Production mix; Low voltage; CZ
Energy Model - Use [B6]Electricity Mix; Production mix; Low voltage; FR
Recyclability Potential In %76
Width Nominal165 mm
[Uc] Control Circuit Voltage120 V
[Uimp] Rated Impulse Withstand Voltage6 kV IEC 60947
Nbr. Of Units In Pkg.1
Take-backNo
Customs Code8536490065
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
- Take Back
- No
- Recycled Metal Content At Cr Level
- 0 %
- Mercury Free
- Yes
- Environmental Disclosure
- ENVPEP1102005EN
- Operating Altitude
- 9842.52 ft (3000 m) without derating
- Packaging Without Single Use Plastic
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- Pep Verification Date
- 2025-11-20
- Psr Version
- PSR-0005-ed2-2016 03 29
Ambient Air Temperature For Storage-60-80 °C, -60-80 °C
Reach Free ShvcYes
Toxic Heavy Metal FreeYes
Carbon Footprint108.21878469436906
Eu Rohs DirectiveCompliant
Packaging Made With Recycled CardboardYes
Reach Free Of SvhcYes
Pep CodeENVPEP1102005EN
Pcr VersionPEP-PCR-ed4-2021 09 06
Type Of Verification For The PepIndependent internal review
General Attributes
- Product Or Component Type
- reversing contactor
Range Of ProductTeSys Deca
ETIM
- ETIM 8
- EC000010
ETIM 9EC000010
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
