Schneider Electric LX1D6M6 TeSys Deca Contactor Coil 220 V AC 60 Hz for 80 & 95 A Contactors
- MPN: LX1D6M6
- PPN: SCH-LX1D6M6
- UNSPSC: 39121529
CAD
$166.18
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
TeSys D replacement AC coil 220V 60Hz for TeSys D contactors. To be used with 3 and 4-pole contactors LC1 D40 to D95. It operates in the voltage limits 0.85-1.1 Uc and environments until 55°C Green Premium compliant (RoHS/REACh).
Documentation & Downloads
Specifications
Key Specifications
| Average Resistance | 98 Ohm 20 °C |
|---|---|
| Control Circuit Type | AC 60 Hz |
| Range | TeSys |
| Maximum Operating Rate | 3600 cyc/h 60 °C |
| Product Compatibility | LC1D40 || LC1D50 || LC1D65...D95 |
| [Uc] Control Circuit Voltage | 220 V AC 60 Hz |
|---|---|
| Product Or Component Type | contactor coil |
| Inductance Of Closed Circuit | 4.8 H |
| Mechanical Durability | 4 Mcycles |
| Device Short Name | LX1D6 |
Complementary
| Control Circuit Voltage Limits | drop-out: 0.3...0.6 Uc at 50/60 Hz (at <55 °C) || operational: 0.8...1.1 Uc at 50 Hz (at <55 °C) || operational: 0.85...1.1 Uc at 60 Hz (at <55 °C) |
|---|---|
| Coil Technology | without built-in suppressor module |
| Heat Dissipation | 6-10 W 50/60 Hz |
| Inrush Power In Va | 220-220 VA 60 Hz cos phi 0.75 (at 20 °C) |
|---|---|
| Hold-In Power Consumption In Va | 22-22 VA 60 Hz cos phi 0.3 (at 20 °C) |
Environment
| Ambient Air Temperature For Operation | -5-60 °C |
|---|
| Net Weight | 0.28 kg |
|---|
Contractual warranty
| Warranty | 18 months |
|---|
Offer Sustainability
| Rohs Exemption Information | Yes |
|---|---|
| Environmental Disclosure | ENVPEP110205EN |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| Reach Free Of Svhc | Yes |
| Circularity Profile | N/A |
| Mercury Free | Yes |
|---|---|
| Sustainable Offer Status | Green Premium product |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
