Square D 8910DP41V14 Definite Purpose Contactor 40A 1 Pole 24V AC 50/60Hz, UL Listed
- MPN: 8910DP41V14
- UPC: 785901233053
- PPN: SCH-8910DP41V14
CAD
$114.38
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Description
8910DP definite purpose magnetic contactors are designed for heating, air conditioning and refrigeration applications. This line of definite purpose contactors has current ratings up to 120 amperes resistive and 50 HP at 600 VAC. This one pole definite purpose contactor has a full load rating of 40 ampere and a resistive rating of 50 amperes at 277 V maximum. The nonreplaceable coil is available with a variety of coil voltages. This device has a 24 VAC 50/60 Hz coil. The contactor has straight through wiring. Contactor is 2.00 inches by 3.29 inches and 2.39 tall. These contactors are UL Listed and CSA Certified.
Documentation & Downloads
Specifications
Key Specifications
- Range Of Product
- DP
- [In] Rated Current
- 40 A
- Pole Contact Composition
- 1 NO
Poles Description1P
Product Or Component TypeDefinite Purpose Contactor
Complementary
- [Uc] Control Circuit Voltage
- 24 V AC 50/60 Hz
- Motor Power Hp
- 2-2 hp 115 V AC, 1 phase || 5-5 hp 230 V AC, 1 phase
- Network Number Of Phases
- 1 phase
Locked Rotor Rated Current240 A 277 V AC || 200 A 460 V AC || 160 A 575 V AC
Electrical Connectionquick connect terminals || box lugs
[Ue] Rated Operational Voltage600 V AC
Environment
- Product Certifications
- UL recognized || CSA
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information
- Mercury Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Rohs Exemption InformationYes
Eu Rohs DirectiveCompliant with Exemptions
