Bussmann LP-CC-6 Class CC Fuse, 600 Vac, 150 Vdc, 6A, Time-Delay, Non-Indicating
Bussmann LP-CC-6 Class CC Fuse, 600 Vac, 150 Vdc, 6A, Time-Delay, Non-Indicating
- MPN: LP-CC-6
- UPC: 051712180344
- PPN: BUS-LP-CC-6
Available to Order
Company Stock:
0
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To view product inventory
CAD$17.20/ EA
Description
Class CC Fuse, 600 Vac, 150 Vdc, 6A, Time-Delay, Non-Indicating
Features
- Engineered specifically for high-density industrial enclosures, this space-saving 13/32" x 1-1/2" Class CC fuse reduces valuable panel footprint by up to 50% compared to traditional Class R alternatives. It features a specialized rejection base that mechanically prevents the dangerous accidental installation of lower-rated supplemental fuses, guaranteeing your automated control boards and branch circuits maintain their precise electrical safety ratings.
- Designed with an advanced time-delay characteristic, this 6-amp fuse safely absorbs temporary, harmless power surges—such as the initial startup currents from small inductive motors, contactors, and control transformers. By effectively preventing frustrating nuisance blowing during normal equipment operation, it actively minimizes factory downtime while still delivering highly sensitive overcurrent protection against sustained, destructive faults.
- Boasting a massive 200,000 Amp short circuit interrupting rating (IR) at 600V AC and 300V DC, this highly efficient current-limiting device stops dangerous fault currents in a fraction of a second. By drastically reducing peak let-through thermal and magnetic energy, it acts as a critical firewall to safeguard expensive relays, PLCs, and solid-state motor controllers from catastrophic thermal damage and dangerous arc flash hazards.
- Fully UL Listed to standard 248-4 and CSA Certified for dedicated branch circuit protection, this industrial-grade Bussmann fuse ensures your machinery installations easily pass the most rigorous local safety inspections. Relying on factory-tested, code-compliant overcurrent hardware guarantees highly reliable performance across demanding manufacturing environments and ensures your facility's commercial operational insurance remains fully valid.
Specifications
- Voltage
- 600 Vac, 150 Vdc
- Interrupting Rating
- 200 kA Vac RMS Sym, 20 kA Vdc
- Time-Delay Duration
- 12 seconds minimum at 200% rated current
- Weight
- 0.15 lb
- Compliance
- CE, UL Listed, CSA Certified, RoHS Compliant
Amperage6 A
Fuse TypeTime-Delay
Size0.41 in W x 0.41 in D x 1.5 in H
Fuse ClassClass CC
