Schneider Electric SSLZRA1 Harmony SSL Relay Socket, 5-24V DC, IP20, 101mm Height
- MPN: SSLZRA1
- PPN: SCH-SSLZRA1
CAD
$13.43
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
This Harmony SSL socket for solid state slim interfacing relay has spring terminals and a rated voltage of 5V DC." "It also offers clear circuit labelling on the sides to facilitate installation and maintenance." "It features a visual indicator LED for a simpler troubleshooting and commissioning." "Its clear schematic on the side of the socket enables easier wiring and maintenance." 0 0 0 0 0 0 0 0 0 0 0 0
Documentation & Downloads
Specifications
Key Specifications
- [Ith] Conventional Free Air Thermal Current
- 6 A
- Product Or Component Type
- socket for SSL1
- Switching Voltage
- 5 V DC || 24 V DC
- [Ue] Rated Operational Voltage
- < 250 V DC
Range Of ProductHarmony Solid State Relays
Product Compatibilitysolid state relay SSL NO 24 V DC || solid state relay SSL NO 5 V DC
Device Short NameSSLZ
Complementary
- Height
- 101 mm
- Clamping Force
- 10-40 N
- Shape Of Pin
- flat
- Net Weight
- 0.0285 kg
- Connections - Terminals
- spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) solid without cable end || spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) flexible with cable end
- Local Signalling
- input status LED green)
- Overvoltage Category
- III
[Uimp] Rated Impulse Withstand Voltage3.6 kV
Pollution Degree3
Contact Terminal Arrangementseparate
Fixing Modeclip-on (35 mm DIN rail)
Sale Per Indivisible Quantity10
Width6.2 mm
Depth78.6 mm
Environment
- Product Certifications
- UL 508 || CSA C22-2 No 14
- Standards
- IEC 61984
- Flame Retardance
- V0 UL 94
- Ip Degree Of Protection
- IP20
Ambient Air Temperature For Operation-40-70 °C
MarkingCE
Ambient Air Temperature For Storage-40-85 °C
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP1405004EN
- Toxic Heavy Metal Free
- Yes
- Reach Free Of Svhc
- Yes
- Circularity Profile
- ENVEOLI1405004EN
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Reach RegulationFree of Substances of Very High Concern above the threshold
China Rohs RegulationX
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
