Weidmuller 1873590000 HDC HE 24 MP

HDC HE 24 MP
HDC HE 24 MP
  • MPN: 1873590000
  • PPN: WDM-1873590000

Spec sheet

Available to Order

Company Stock:

0

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Looking to buy a large quantity?

To view product inventory

CAD$18.90/ EA

Description

HDC insert, Pin, 500 V, 16 A, Number of poles: 24, PUSH IN, Size: 8

Specifications

General Data

Insulating material
PC glass-fibre reinforced (UL-listed and railway-certified)
Insulation strength
1010 Ω
Number of poles
24
Pollution severity
3
Rated impulse voltage (DIN EN 61984)
6 kV
Rated voltage according to UL/CSA
600 V AC/DC
Size
8
Type
Pin
Volume resistance
≤ 2mΩ
Insulating material groupIIIa
MaterialCopper alloy
Plugging cycles, silver≥ 500
Rated current (DIN EN 61984)16 A
Rated voltage (DIN EN 61984)500 V
SeriesHE
Surface finishSilver passivated
UL 94 flammability ratingV-0

Approvals

Approvals
CSA, cURus, DNV GL, EAC
UL File Number Search
E92202
ROHSConform

Dimensions And Weights

Width
34 mm
Height
34.3 mm
Depth
111 mm
Net weight
104 g
Width (inches)1.339 inch
Height (inches)1.35 inch
Depth (inches)4.37 inch

General Descriptions

Number of poles
24
Size8

Dimensions

Height of plug
34.3 mm
Total length base111 mm

Version

Blade size, slotted (screw connection)
SD 0.5 x 3.0
Conductor cross-section, min.
0.5 mm²
Size
8
Surface finish
Silver passivated
Volume resistance
≤ 2mΩ
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, max.
2.5 mm²
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.
1.5 mm²
Wire connection cross-section, finely stranded, min.
0.5 mm²
Wire cross-section, solid, min.
0.5 mm²
Conductor cross-section, max.2.5 mm²
MaterialCopper alloy
Stripping length, rated connection10 mm
Type of connectionPUSH IN
Wire connection cross section, finely stranded, max.2.5 mm²
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, min.0.5 mm²
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.0.5 mm²
Wire cross-section, solid, max.1.5 mm²

Material

Insulating material
PC glass-fibre reinforced (UL-listed and railway-certified)
UL 94 flammability rating
V-0
Colourbeige
MaterialCopper alloy

Connection Data

Conductor cross-section, min.
0.5 mm²
Conductor cross-section, max.2.5 mm²

Connection Data Pe

Blade size, crosshead
size PH1
Connection type PE
Screw connection
Rated cross-section
4 mm²
Tightening torque, max. PE connection
1.5 Nm
Wire connection cross section, finely stranded, max.
2.5 mm²
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.
0.5 mm²
Wire cross section, AWG (PE), max.
AWG 12
Wire cross-section, solid, max.
1.5 mm²
Blade size, slotted (PE connection)SD 0.8 x 4.0
Fixing screwM 4
Stripping length PE connection10 mm
Tightening torque, min. PE connection1.2 Nm
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.1.5 mm²
Wire connection cross-section, finely stranded, min.0.5 mm²
Wire cross section, AWG (PE), min.AWG 20
Wire cross-section, solid, min.0.5 mm²

Classifications

ETIM 6.0
EC000438
eClass 9.0
27-44-02-05
eClass 10.0
27-44-02-05
ETIM 7.0EC000438
eClass 9.127-44-02-05
UNSPSC30-21-18-01

Environmental Product Compliance

REACH SVHC
Lead 7439-92-1

Design

Product family
HDC insert
Type
Pin
Blade size, crosshead
size PH1
Product typeInsert
Type of connectionPUSH IN

Temperatures

Limit temperature
-40 °C ... 125 °C
