Schneider Electric LUALB1 TeSys Ultra Limiter Disconnector 32A 50kA Activation Direct Mounting
- MPN: LUALB1
- UPC: 785901291817
- PPN: SCH-LUALB1
CAD
$392.82
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
TeSys U short circuit current limiter block to be connected in series and upstream of a TeSys U starter controller. It increases the starter controller ability to withstand the short circuit current from 50 kA to 130 kA under 400 V. It includes a limiter cartridge LUALF1. To be mounted directly on the upstream terminals of a power base, it must be connected to one power base only.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Mexico
Important Information Attributes
- Persona Type Ids
- EU, LC, OM, OM8, PB
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Tightening Torque
- 1.9-2.5 N.m flat Ø 6 mm, 1.9-2.5 N.m Philips No 2
- Connections - Terminals
- connector 2 x 1-6 mm² flexible without cable end, connector 2 x 1.5-6 mm² solidconnector 1 x 1-10 mm² flexible without cable end, connector 1 x 1-6 mm² flexible with cable end, connector 2 x 1-6 mm² flexible with cable end, connector 1 x 1.5-10 mm² solid
- Local Publishable Date
- 2026-03-31
- Stocking Flag
- N
- Serviceability
- No
- Field Service Division
- PPIBS
- Weee Scope
- In
- Scope Perimeter
- At least in Europe
- Reach Full Compliance Status Id
- NOT_CONTAINING_SVHC
- Rohs Eur In Scope
- Yes
- Rohs Eur Conformity Date
- 2023
- China Rohs In Scope
- Yes
- With Recycled Cardboard
- Yes
- Product Contributes To Saved And Avoided Emissions
- No
- Tier
- 2
- Function Option
- Standard
- Compatibility Code
- LUA
- Energy Efficiency Optimized
- False
- Product Availability
- Stock - Normally stocked in distribution facility
- Range
- TeSys
- Returnability
- Yes
- Weee Label
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Nbr. Of Units In Pkg.
- 1
- Take-back
- No
Persona Type NamesEnd User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
Market SegmentationCommercial, Industrial
[Ui] Rated Insulation Voltage690 V EN 60947-1, 690 V IEC 60947-1
Local Data StatusPublishable
Return IndicatorY
Stock Policy2
TraceabilityNo
Weee ApplicabilityFinished product
Weee Product Category5
Reach Full Compliance StatusFree of Substances of Very High Concern above the threshold
Reach Compliance DirectiveFree of Substances of Very High Concern above the threshold
Rohs Eur StatusCompliant
Rohs Eur Full Compliance StatusCompliant
China Rohs Label1
Without Single Use PlasticYes
Tier Id2
Function Option IdSTANDARD
Product Kit IdentifierN
Device Short NameLUA
Mounting Modedirect
Product Or Component Typelimiter disconnector
Range Of ProductTeSys Ultra
Sustainable PackagingNo
[Ith] Conventional Free Air Thermal Current32 A
Package Weight(Lbs)330.000 g
Warranty (In Months)18
Environment Attributes Main
- Product Compatibility
- LUB, LU2B
- Reach Free Shvc
- Yes
- China Rohs Regulation
- X
- Mercury Free
- Yes
- Packaging Made With Recycled Cardboard
- Yes
- Reach Free Of Svhc
- Yes
Take BackNo
Recycled Metal Content At Cr Level0 %
Toxic Heavy Metal FreeYes
Eu Rohs DirectiveCompliant
Packaging Without Single Use PlasticYes
Reach RegulationFree of Substances of Very High Concern above the threshold
General Attributes
- Product Or Component Type
- limiter disconnector
Range Of ProductTeSys Ultra
ETIM
- ETIM 8
- EC000239
ETIM 9EC000239
