Schneider Electric XACS499 Harmony XAC Isolating Block, 30mm Vertical Fixing, 3NC, 3000W

MPN: XACS499
PPN: SCH-XACS499
UNSPSC: 39121522

$202.97

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This isolating block is a separate component for double insulated, XACB pendant control station, for power circuits. It is designed for emergency stop applications. It features 2 N/C + N/C with positive opening operation contacts ans screw connection. In the interests of safety, it is imperative that this isolating block only be used with a stay put or latching type operating head to ensure complete isolation when the pendant station is not in use.

Features

Screw clamp terminal connections
Complies with IEC standards
Mechanical durability of 1 million cycles
Wide range of operating temperature from -25°C to 70°C

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Czechia

Weight	88 g

Complementary Attributes

Rated Operational Power In W	3000 W AC-23B 400 V
Uimp Rated Impulse Withstand Voltage	6 kV IEC 60947-1

Ui Rated Insulation Voltage	400 V 3)IEC 60947-1

Important Information Attributes

Persona Type Ids	BM9, EU, LC, OM, OM8, PB, SC, SI, VR
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Connections Terminals	screw clamp terminals, 1 x 2.5 mm² with or without cable end, screw clamp terminals, 2 x 1.5 mm² with or without cable end
Carbon Footprint Of The Distribution Phase A4	0.0178577778, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase A5	0.0004255932, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase B2 B3 B4 B6	kg CO2 eq., 0
Local Publishable Date	2026-01-12
Weee Scope	In
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Reference contains Substances of Very High Concern above the threshold
Reach Compliance Directive	Reference contains Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant By Exemption
Rohs Eur Full Compliance Status	Compliant By Exemption
China Rohs Label	5
Without Single Use Plastic	No
Tier Id	2
Function Option Id	STANDARD
Product Kit Identifier	N
Contact Block Application	emergency stop push-button
Contact Code Designation	A300 AC-15, Ue = 240 V, Ie = 3 A IEC 60947-5-1 appendix AQ300 DC-13, Ue = 250 V, Ie = 0.27 A IEC 60947-5-1 appendix A
Contacts Type And Composition	3 NC
Electrical Shock Protection Class	class II conforming to IEC 61140
Mounting Of Block	front mounting
Product Or Component Type	isolating block
Returnability	No
Software Version	EIME v5.9.4
Total Lifecycle Carbon Footprint	0.5 kg CO2 eq.
Vibration Resistance	15 gn (f= 10-500 Hz) conforming to IEC 60068-2-6
Database Version	2022-01
Nbr. Of Units In Pkg.	1
Warranty In Months	18
Functional Unit Quantity	1
Reference Lifetime In Y	10

Persona Type Names	Charge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner
Market Segmentation	Commercial, Industrial
Certificate Agency	IEC 60947-3, CSA C22.2 No 14
Carbon Footprint Of The End Of Life Phase C1 To C4	0.1 kg CO2 eq., 0.0771076923
Carbon Footprint Of The Manufacturing Phase A1 To A3	0.4 kg CO2 eq., 0.4226803419
Local Data Status	Publishable
Return Indicator	N
Weee Product Category	5
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	CONTAINS_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	1930
China Rohs In Scope	Yes
With Recycled Cardboard	No
Product Contributes To Saved And Avoided Emissions	No
Tier	2
Function Option	Standard
Component Name	XACS
Contact Block Type	single
Contact Operation	snap action
Electrical Circuit Type	power circuit
Mechanical Durability	1000000 cycles
Product Availability	Non-Stock - Not normally stocked in distribution facility
Range Of Product	Harmony XAC
Shock Resistance	100 gn IEC 60068-2-27
Sustainable Packaging	No
Vertical Fixing Centres	30 mm
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Data Source	extrapolated product
Customs Code	8538100000
Functional Unit Description	XAC is a complete ready to use pendant station for control of single-speed motors in Industrial application which has 10 years of product lifetime with 15% of use rate.& 10Product Standards- EN/IEC 60947-5-1, EN/IEC 60204-32
Functional Unit Unit	Unit
Recyclability Potential In %	32

Environment Attributes Main

Ambient Air Temperature For Operation	-25-70 °C, -25-70 °C
Take Back	No
China Rohs Regulation	X
Carbon Footprint	0.5180714051
Eu Rohs Directive	Compliant By Exemption
Packaging Without Single Use Plastic	No
Reach Regulation	Reference contains Substances of Very High Concern above the threshold
Pep Verification Date	2022-11-01
Psr Version	PSR-0005-ed2-2016 03 29

Ambient Air Temperature For Storage	-40-70 °C, -40-70 °C
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Environmental Disclosure	ENVPEP0709005EN
Packaging Made With Recycled Cardboard	No
Product Compatibility	XACB
Pep Code	ENVPEP0709005EN
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review
