Schneider Electric LA7D03F TeSys Deca Thermal Overload Relay, 110V AC/DC, 100 VA Inrush Power

MPN: LA7D03F
PPN: SCH-LA7D03F
UNSPSC: 39122330

$130.68

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

TeSys LRD remote control device for thermal overload relays LRD43../LR3D15../LR2D../LRD33../LRD43../LR3D35.. It provides a 110V AC/DC control circuit to perform a remote tripping and electrical reset. Sustainability compliant.

Features

Add on design to ensure product flexibility
New Product signature to align with TeSys Deca series
Easier to install and operate with multi-standard screws
Environmental performance of the product

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Czechia, France, United States

Complementary Attributes

Uc Control Circuit Voltage	110 V AC 50/60 Hz, 110 V DC

Maximum Inrush Power In Va	100 VA

Important Information Attributes

Persona Type Ids	EU, LC, OM, OM8, PB, SC
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Control Circuit Voltage 4	110 V
Local Data Status	Publishable
Return Indicator	Y
Traceability	No
Weee Scope	In
Scope Perimeter	At least in Europe
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	Yes
Rohs Eur Conformity Date	1901
China Rohs In Scope	No
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Compatibility Code	LA7D
Energy Efficiency Optimized	False
Product Availability	Stock - Normally stocked in distribution facility
Range	TeSys
Sustainable Packaging	Yes
Accessory / Separate Part Category	electrical accessory
Customs Code	8538908180

Persona Type Names	End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician
Market Segmentation	Commercial, Industrial
Control Circuit Voltage 4 Control Circuit Voltage	110 V
Local Publishable Date	2026-07-07
Serviceability	No
Field Service Division	PPIBS
Weee Product Category	5
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	Yes
Tier Id	1
Function Option Id	STANDARD
Product Kit Identifier	N
Device Short Name	LA7D
Inrush Power In W	0-100 W
Product Or Component Type	electrical remote tripping
Returnability	Yes
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Nbr. Of Units In Pkg.	1
Warranty In Months	18

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Take Back	No
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes

Product Compatibility	LRD43.., LR3D15.., LR2D, LRD33.., LR3D43.., LR3D35.., LRD15.., LR3D33..
Reach Free Shvc	Yes
Toxic Heavy Metal Free	Yes
Eu Rohs Directive	Compliant
Packaging Without Single Use Plastic	Yes
Reach Regulation	Free of Substances of Very High Concern above the threshold
