Schneider Electric LA7D03M TeSys Deca Thermal Overload Relay 220/230V AC/DC
- MPN: LA7D03M
- PPN: SCH-LA7D03M
CAD
$130.68
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
TeSys LRD remote control device for thermal overload relays LR2D/LR3D35../LRD15../LR3D33../LRD33../LRD43../LR3D43.. It provides a 220...230V AC/DC control circuit to perform a remote tripping and electrical reset. Sustainability compliant.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Brazil, Czechia, France
Complementary Attributes
- Maximum Inrush Power In Va
- 100 VA
Important Information Attributes
- Persona Type Ids
- EU, LC, OM, OM8, PB, SC
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- [Uc] Control Circuit Voltage
- 220/230 V AC 50/60 Hz, 220/230 V DC
- Local Publishable Date
- 2025-07-30
- Stocking Flag
- Y
- Serviceability
- No
- Field Service Division
- PPIBS
- Weee Product Category
- 5
- Reach Full Compliance Status
- Free of Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Free of Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant
- Rohs Eur Full Compliance Status
- Compliant
- China Rohs Label
- 1
- Without Single Use Plastic
- Yes
- Tier Id
- 1
- Function Option Id
- STANDARD
- Product Kit Identifier
- N
- Device Short Name
- LA7D
- Inrush Power In W
- 0-100 W
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Range
- TeSys
- Sustainable Packaging
- Yes
- Control Circuit Voltage 4
- 220/230 V
- Accessory / Separate Part Category
- electrical accessory
- Package Weight(Lbs)
- 106.0 g
- Warranty (In Months)
- 18
Persona Type NamesEnd User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician
Market SegmentationCommercial, Industrial
Local Data StatusPublishable
Return IndicatorN
Stock Policy2
TraceabilityNo
Weee ScopeIn
Scope PerimeterAt least in Europe
Reach Full Compliance Status IdNOT_CONTAINING_SVHC
Rohs Eur In ScopeYes
Rohs Eur Conformity Date1901
China Rohs In ScopeNo
With Recycled CardboardYes
Product Contributes To Saved And Avoided EmissionsNo
Tier1
Function OptionStandard
Compatibility CodeLA7D
Energy Efficiency OptimizedFalse
Maximum Inrush Power In Va100 VA
Product Or Component Typeelectrical remote tripping
ReturnabilityNo
Weee LabelThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Control Circuit Voltage 4 Control Circuit Voltage220/230 V
Nbr. Of Units In Pkg.1
Take-backNo
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
- Take Back
- No
- Recycled Metal Content At Cr Level
- 0 %
- Mercury Free
- Yes
- Packaging Made With Recycled Cardboard
- Yes
- Reach Free Of Svhc
- Yes
Product CompatibilityLR2D, LR3D35.., LRD15.., LRD33.., LR3D33.., LR3D43.., LRD43.., LR3D15..
Reach Free ShvcYes
Toxic Heavy Metal FreeYes
Eu Rohs DirectiveCompliant
Packaging Without Single Use PlasticYes
Reach RegulationFree of Substances of Very High Concern above the threshold
General Attributes
- Product Or Component Type
- electrical remote tripping
ETIM
- ETIM 8
- EC002027
ETIM 9EC002027
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
