Schneider Electric CHOM2125 Homeline Miniature Circuit Breaker, 125A, 2 Pole, 120/240V AC, 10kA
- MPN: CHOM2125
- UPC: 785901648185
- PPN: SCH-CHOM2125
CAD
$315.92
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
CHOM Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. CHOM breakers provide 10kA breaking capacity. The electrical connection is a clamp terminal that will accept 2 wires. The clamp terminal will accept a wire range of 4 AWG to 2/0 AWG copper or aluminum wire. CHOM Homeline miniature circuit breakers are CSA certified.
Features
- Engineered with a robust 125-Amp rating, this double-pole breaker provides the muscle needed to feed a secondary garage panel, workshop sub-panel, or heavy-draw residential equipment like tankless water heaters and vehicle charging stations. It manages large electrical demands simultaneously, eliminating frequent nuisance trips and keeping your home's heavy infrastructure running smoothly.
- Featuring a 10,000-amp short-circuit interrupting capacity at 120/240V AC, this breaker acts as a fast-acting shield for your home's wiring. It is engineered to instantly detect and quench dangerous high-current short circuits and severe overloads, isolating the fault in milliseconds to prevent electrical fires and protect your connected household appliances from catastrophic damage.
- Outfitted with an internal common-trip mechanism, this breaker guarantees that a fault on either leg of the 240V circuit will instantly trip both poles at the exact same time. This essential safety feature completely eliminates the risk of "half-tripping," preventing dangerous back-feeding and ensuring that the entire downstream circuit is fully de-energized during maintenance or fault conditions.
Documentation & Downloads
Specifications
Key Specifications
- Circuit Breaker Application
- not rated
- Circuit Breaker Type
- standard
- Range Of Product
- Homeline
- Electrical Connection
- screw clamp terminals
- Product Or Component Type
- miniature circuit-breaker
Mounting Modeplug-on
Short-Circuit Current10 kA
Poles Description2P
[In] Rated Current125 A
[Ue] Rated Operational Voltage120/240 V AC
Complementary
- Number Of Spaces Required
- 2
Awg GaugeAWG 4...AWG 2/0 aluminum/copper
Offer Sustainability
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information
- Mercury Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Rohs Exemption InformationYes
Eu Rohs DirectiveCompliant with Exemptions
Environment
- Product Certifications
- CSA
Ambient Air Temperature For Operation40 °C
