Schneider Electric LC1D188FD TeSys Deca 4P Contactor, 32A, 110V DC Coil, Compact Design
- MPN: LC1D188FD
- PPN: SCH-LC1D188FD
CAD
$439.82
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
TeSys D contactor, 4 poles (2NO+2NC), for non-inductive load applications up to 32A/690V AC-1. It provides a 110V DC coil with transient suppressor module, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
Documentation & Downloads
Specifications
Key Specifications
| [Uc] Control Circuit Voltage | 110 V DC |
|---|---|
| Range Of Product | TeSys Deca |
| Product Or Component Type | contactor |
| [Ie] Rated Operational Current | 32 A (at <60 °C) at <= 440 V AC AC-1 for power circuit |
| Device Short Name | LC1D |
| [Ue] Rated Operational Voltage | power circuit <= 690 V AC 25...400 Hz |
|---|---|
| Contactor Application | resistive load |
| Utilisation Category | AC-1 || AC-3 || AC-3e || AC-4 |
| Poles Description | 4P |
Complementary
| Non-Overlap Time | 1.5 ms on de-energisation between NC and NO contact || 1.5 ms on energisation between NC and NO contact |
|---|---|
| Power Dissipation Per Pole | 2.5 W AC-1 |
| Auxiliary Contact Composition | 1 NO + 1 NC |
| Control Circuit Voltage Limits | 0.1...0.25 Uc -40-60 °C drop-out DC || 0.7...1.25 Uc -40-60 °C operational DC |
| Contact Compatibility | M7 |
| Safety Reliability Level | B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1 || B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1 |
| Hold-In Power Consumption In W | 5.4-5.4 W 20 °C |
| Rated Breaking Capacity | 300 A at 440 V for power circuit conforming to IEC 60947 |
| Associated Fuse Rating | 10 A gG for signalling circuit conforming to IEC 60947-5-1 || 50 A gG at <= 690 V coordination type 1 for power circuit || 35 A gG at <= 690 V coordination type 2 for power circuit |
| Pole Contact Composition | 2 NO + 2 NC |
| Coil Technology | with integral suppression device |
| Operating Time | 63 ±15 % ms closing || 20 ±20 % ms opening |
| Maximum Operating Rate | 3600 cyc/h 60 °C |
| Tightening Torque | control circuit 1.7 N.m screw clamp terminals flat Ø 6 mm || control circuit 1.7 N.m screw clamp terminals Philips No 2 || control circuit 1.7 N.m screw clamp terminals pozidriv No 2 || power circuit 1.8 N.m screw clamps terminals flat Ø 6 mm || power circuit 1.8 N.m screw clamps terminals Philips No 2 || power circuit 1.8 N.m screw clamp terminals pozidriv No 2 |
| Mechanical Durability | 30 Mcycles |
| Auxiliary Contacts Type | mechanically linked 1 NO + 1 NC IEC 60947-5-1 || mirror contact 1 NC IEC 60947-4-1 |
| Overvoltage Category | III |
| [Icw] Rated Short-Time Withstand Current | 145 A 40 °C - 10 s for power circuit || 240 A 40 °C - 1 s for power circuit || 40 A 40 °C - 10 min for power circuit || 84 A 40 °C - 1 min for power circuit || 100 A - 1 s for signalling circuit || 120 A - 500 ms for signalling circuit || 140 A - 100 ms for signalling circuit |
| Minimum Switching Current | 5 mA for signalling circuit |
|---|---|
| Average Impedance | 2.5 mOhm - Ith 32 A 50 Hz for power circuit |
| [Ith] Conventional Free Air Thermal Current | 10 A (at 60 °C) for signalling circuit || 32 A (at 60 °C) for power circuit |
| Mounting Support | plate || rail |
| Control Circuit Type | DC standard |
| Pollution Degree | 3 |
| Insulation Resistance | > 10 MOhm for signalling circuit |
| Irms Rated Making Capacity | 140 A AC for signalling circuit conforming to IEC 60947-5-1 || 250 A DC for signalling circuit conforming to IEC 60947-5-1 || 300 A at 440 V for power circuit conforming to IEC 60947 |
| [Uimp] Rated Impulse Withstand Voltage | 6 kV IEC 60947 |
| Connections - Terminals | control circuit: screw clamp terminals 1 1-4 mm² - cable stiffness: flexible without cable end || control circuit: screw clamp terminals 2 1-4 mm² - cable stiffness: flexible without cable end || control circuit: screw clamp terminals 1 1-4 mm² - cable stiffness: flexible with cable end || control circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: flexible with cable end || control circuit: screw clamp terminals 1 1-4 mm² - cable stiffness: solid without cable end || control circuit: screw clamp terminals 2 1-4 mm² - cable stiffness: solid without cable end || power circuit: screw clamp terminals 1 2.5-10 mm² - cable stiffness: flexible without cable end || power circuit: screw clamp terminals 2 2.5-10 mm² - cable stiffness: flexible without cable end || power circuit: screw clamp terminals 1 2.5-10 mm² - cable stiffness: flexible with cable end || power circuit: screw clamp terminals 2 2.5-10 mm² - cable stiffness: flexible with cable end || power circuit: screw clamp terminals 1 2.5-16 mm² - cable stiffness: solid without cable end || power circuit: screw clamp terminals 2 2.5-16 mm² - cable stiffness: solid without cable end |
| Time Constant | 28 ms |
| Minimum Switching Voltage | 17 V for signalling circuit |
| Signalling Circuit Frequency | 25...400 Hz |
| Electrical Durability | 1 Mcycles 32 A AC-1 <= 440 V |
| Inrush Power In W | 5.4-5.4 W 20 °C) |
| Compatibility Code | LC1D |
| [Ui] Rated Insulation Voltage | power circuit 690 V IEC 60947-4-1 || power circuit 600 V CSA || power circuit 600 V UL || signalling circuit 690 V IEC 60947-1 || signalling circuit 600 V CSA || signalling circuit 600 V UL |
| Protective Cover | with |
Environment
| Product Certifications | UL || CSA || CCC || EAC || UKCA || CB || EU-RO-MR by DNV-GL |
|---|---|
| Standards | EN 60947-4-1 || EN 60947-5-1 || IEC 60947-4-1 || IEC 60947-5-1 || UL 60947-4-1 || UL 60947-5-1 || CSA C22.2 No 60947-4-1 || CSA C22.2 No 60947-5-1 || GB/T 14048.4 |
| Net Weight | 0.585 kg |
| Protective Treatment | THIEC 60068-2-30 |
| Mechanical Robustness | vibrations contactor open 2 Gn, 5...300 Hz) || vibrations contactor closed 4 Gn, 5...300 Hz) || shocks contactor open 10 Gn for 11 ms) || shocks contactor closed 15 Gn for 11 ms) |
| Fire Resistance | 850 °C IEC 60695-2-1 |
| Depth | 107 mm |
| Height | 91 mm |
|---|---|
| Climatic Withstand | IACS E10 exposure to damp heat || IEC 60947-1 Annex Q category D exposure to damp heat |
| Flame Retardance | V1 UL 94 |
| Ip Degree Of Protection | IP20 front face IEC 60529 |
| Operating Altitude | 0...3000 m |
| Width | 45 mm |
| Permissible Ambient Air Temperature Around The Device | -40-60 °C || 60-70 °C with derating |
Contractual warranty
| Warranty | 18 months |
|---|
Offer Sustainability
| Rohs Exemption Information | Yes |
|---|---|
| Environmental Disclosure | ENVPEP110230EN |
| Pvc Free | Yes |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information |
| Eu Rohs Directive | Compliant with Exemptions |
| Mercury Free | Yes |
|---|---|
| Sustainable Offer Status | Green Premium product |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| Circularity Profile | ENVEOLI1102030EN |
