Schneider Electric LC1D115T7 TeSys Deca Contactor 3P 115A 480V AC 50/60Hz, IP20
- MPN: LC1D115T7
- PPN: SCH-LC1D115T7
CAD
$1054.02
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Engineered for robust performance in demanding applications, the TeSys Deca Contactor from Schneider Electric is designed to manage high-efficiency electrical control systems with ease. This model accommodates three poles and handles up to 115A, making it suitable for a variety of industrial environments powered by 480V AC at both 50 and 60Hz. With an IP20 rating, it offers adequate protection against dust and contact, ensuring reliability and safety in your automation and control setup. The TeSys Deca Contactor stands out as a dependable choice for those seeking a high-performance solution within the realm of starters and contactors.
Documentation & Downloads
Specifications
Additional
- Rated Operational Current
- 200 A AC-1, 115 A AC-3, 115 A AC-3e at <= 440 V AC
- Rated Short-Time Withstand Current
- 1100 A at 40 °C for 1 s, 950 A at 40 °C for 10 s, 550 A at 40 °C for 1 min, 250 A at 40 °C for 10 min power circuit; 100 A 1 s signalling circuit; 120 A 500 ms signalling circuit; 140 A 100 ms signalling circuit
- Rated Insulation Voltage
- 600 V CSA, 600 V UL, 1000 V IEC 60947-4-1 power circuit; 690 V IEC 60947-1 signalling circuit
- Overvoltage Category
- III
- Electrical Durability
- 0.8 Mcycles (200 A AC-1 <= 440 V), 0.95 Mcycles (115 A AC-3 and AC-3e <= 440 V)
- Hold-in Power Consumption
- 2-18 VA cos phi 0.3 at 50/60 Hz (20 °C)
- Operating Time
- 6-20 ms opening, 20-50 ms closing
- Minimum Switching Current
- 5 mA signalling circuit
- Pole Contact Composition
- 3 NO
- Voltage
- 480 V AC 50/60 Hz
- Dimensions
- Height 158 mm (6.22 in), Width 120 mm (4.72 in), Depth 136 mm (5.35 in)
- Mounting Support
- Rail, Plate
- IP Rating
- IP20 front face IEC 60529
- Operating Altitude
- 0 to 3000 m (0 to 9843 ft)
- Compliance
- CSA C22.2 No 14, EN 60947-4-1, EN 60947-5-1, UL 508, CCC, GOST, Lloyd's Register, RINA, DNV, UKCA, CE, RoHS Compliant
Rated Breaking Capacity1100 A at 440 V AC
Maximum Operating Rate2400 cycles/hour at 60 °C
Rated Impulse Withstand Voltage8 kV IEC 60947
Pollution Degree3
Mechanical Durability8 Mcycles
Inrush Power280-350 VA cos phi 0.8 at 50/60 Hz (20 °C)
Minimum Switching Voltage17 V signalling circuit
Auxiliary Contact Composition1 NO + 1 NC mechanically linked
Poles3P
Motor Power30 hp at 200/208 V; 40 hp at 230/240 V; 75 hp at 460/480 V; 100 hp at 575/600 V AC 50/60 Hz 3 phase; 30 kW at 220-230 V; 55 kW at 380-400 V; 59 kW at 415-440 V; 75 kW at 500 V; 80 kW at 660-690 V; 65 kW at 1000 V AC (AC-3 and AC-3e)
Net Weight2.5 kg (5.51 lb)
Material and Construction CompliancePVC Free, Flame Retardance V1 UL 94, Fire Resistance 850 °C IEC 60695-2-1
Operating Temperature Range-40 to 60 °C (-40 to 140 °F); 60 to 70 °C (140 to 158 °F) with derating
Coil TechnologyBuilt-in bidirectional peak limiting diode suppressor
Country of OriginCZ (Czech Republic)
